A.5.8 Wireless LAN Interface (Radio 2)
WLAN standards
Frequency bands 5 GHz indoor
(EU)
Frequency bands 5 GHz out-
door (EU)
WLAN modes
Modulation Techniques
Automatic Rate Selection (ARS) Available.
Transmission rate
Data rates
Short guard interval (802.11n)
Output power limitation
Output power @ 5 GHz
Bandwidth (802.11ac)
Antenna
A.5.9 Configuration Interface
LOCAL TERMINAL
CONNECTOR
A.5.10 Power Supply
INPUT VOLTAGE
INPUT CURRENT
CONNECTOR
Teldat Connect-KFPlus
IEEE 802.11ac/an; MU-MIMO 2x2; 20/40/80 MHz; 5 GHz
5 GHz indoor (5150-5350 MHz) max. 200 mW EiRP allowed
5 GHz outdoor (5470-5725 MHz) max. 1000 mW EiRP allowed
5 GHz Operation: 802.11a only; 802.11a/n; 802.11n.
OFDM: BPSK, QPSK, DBPSK, DQPSK,16-QAM, 64-QAM, 256-QAM.
Automatic.
802.11a,h (5 GHz): 54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation).
802.11n, 20 MHz channel bandwidth: MCS0-15 allow up to 150 Mbps PHY rate at
20 MHz channel bandwidth, 2 streams, short guard interval.
802.11n, 40 MHz channel bandwidth: MCS0-15 allow up to 300 Mbps PHY rate at
40 MHz channel bandwidth, 2 streams, short guard interval.
802.11ac, 20 MHz channel bandwidth: Allow up to 173 Mbps PHY rate with two
streams or up to 87 Mbps PHY with one stream.
802.11ac, 40 MHz channel bandwidth: Allow up to 400 Mbps PHY rate with two
streams or up to 200 Mbps PHY with one stream.
802.11ac, 80 MHz channel bandwidth: Allow up to 867 Mbps PHY rate with two
streams or up to 433 Mbps PHY with one stream.
On/off switchable; increase of throughput by reducing the guard intervals from
800ns to 400ns.
Adjustable.
Max. 18,12 dBm (200mW EiRP).
20/40/80 MHz.
Integrated directional dual-band MIMO array with 4.88 dB peak gain @ 5 GHz.
RS-232 9600-8-N-1 without flow control.
RJ45 female on the rear panel.
+12V DC.
2.1 A.
Jack 5.5/2.5 mm.
Technical Information
