B.2 RF GSM/WCDMA specifications
The GSM/WCDMA model with the MC8705 module provides WCDMA, GSM, GPRS and EDGE network connectivity
over several radio frequency bands, in accordance with 3GPP standards.
This product is supplied without any antennas. The operator must make sure that the antennas of his/her picking
comply with the local regulations.
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+
Bands
Band 1
Band 2
Band 5
Band 6
Band 8
Technology: GSM / GPRS / EDGE
Bands
GSM 850 (850 MHz)
EGSM 900 (900 MHz)
DCS 1800 (1800 MHz)
PCS 1900 (1900 MHz)
Teldat H2 Automotive Router
Rx: 869–894 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 1850–1910 MHz
Rx: 1930–1990 MHz
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1850–1910 MHz
Rx: 1930–1990 MHz
Tx: 824–849 MHz
Rx: 869–894 MHz
Tx: 830–840 MHz
Rx: 875–885 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Frequencies
Tx: 824–849 MHz
Rx: 869–894 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 1850–1910 MHz
+27 dBm ± 1 dB
+32 dBm ± 1 dB
+27 dBm ± 1 dB
+29 dBm ± 1 dB
+26 dBm ± 1 dB
+29 dBm ± 1 dB
+26 dBm ± 1 dB
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+23 dBm ± 1 dB
Conducted Transmit Power
+32 dBm ± 1 dB
+27 dBm ± 1 dB
+32 dBm ± 1 dB
+27 dBm ± 1 dB
+29 dBm ± 1 dB
+26 dBm ± 1 dB
+29 dBm ± 1 dB
Radio Information
