3 Components and Power Supply

3.2.2 Outline drawing

An outline drawing is provided for proper installation.
Outline drawing
Fig. 5:

3.3 Power source

The Teldat H2 Automotive router family is powered through direct current (DC).
Workplace Conditions. Main Characteristics
• Avoid humid and/or dusty locations.
• Avoid direct exposure to sunlight and any other heat sources. Do not place the device between papers, magazines
or other items that could hinder natural air circulation.
• Do not place the device near strong electromagnetic fields such as those produced by speakers, motors, etc.
• The device should not be placed too close to the driver or in areas where it might distract him/her.
• Avoid knocks and/or strong vibrations during operation, storage and transport.
• The device should be mounted in accordance with accepted aftermarket practices and materials.
Warning
The electric current in power cables, telephone lines and communication cables is dangerous. To pre-
vent electric shocks, before installing, handling or opening the equipment covers, connect and discon-
nect the cables following the steps set forth in

3.3.1 Connecting the power cable to the vehicle

The device power supply cable must be connected to the vehicle's fuse box. Always follow the recommendations of
the vehicle manufacturer on the connection of electrical accessories.
The following are some general tips:
8
Connecting on page 9 and Disconnecting on page 9.
