Table 3-7: GPIO LEDs
Reference Designator
LED4
LED6
LED7
Reset ( LED8 )
When ON (red), it indicates that the board is in reset. A master reset is asserted by pressing SW2 , which activates
the LED. For more information, see
Connectors
This section describes connector functionality and provides information about mating connectors. The connector
locations are shown in the Connector Locations figure.
Figure 3-8: Connector Locations Top View
®
EV-21569-SOM
Manual
Programmable Flag Pin
SoftSwitch
SoftSwitch
SoftSwitch
Reset Pushbutton ( SW2
P1
JTAG
).
LEDs
P2
Micro
USB
3–11
