SoM Interface Connection ( J1,J2,and J3 )

The SoM Interface consists of three SAMTEC high speed connectors that provide the DSP peripheral signals for use
with a plug in baseboard. The SoM Connector figure shows the connector locations on the back of the board.
These signals are based upon the peripheral signal needs, which allows multiple DSPs to be used with this connec-
tion. These connectors are self-mating and the pinout here reflects the connectors on the EV-21569-SOM.
The SoM Interface A Connector (J1), SoM Interface B Connector (J2), and SoM Interface C Connector (J3) tables show
the signal associated with each pin on the connectors.
Table 3-8: SoM Interface A Connector (J1)
Pin Signal
1 GND1
2 GND2
3 DAI0_PIN01
4 DAI1_PIN01
5 DAI0_PIN02
6 DAI1_PIN02
7 DAI0_PIN03
8 DAI1_PIN03
9 DAI0_PIN04
10 DAI1_PIN04
11 DAI0_PIN05
12 DAI1_PIN05
13 DAI0_PIN06
14 DAI1_PIN06
15 DAI0_PIN07
16 DAI1_PIN07
17 DAI0_PIN08
18 DAI1_PIN08
19 DAI0_PIN09
20 DAI1_PIN09
Table 3-9: SoM Interface B Connector (J2)
Pin Signal
1 GND1
®
EV-21569-SOM Manual
Pin Signal Pin
21 DAI0_PIN10 41
22 DAI1_PIN10 42
23 DAI0_PIN11 43
24 DAI1_PIN11 44
25 DAI0_PIN12 45
26 DAI1_PIN12 46
27 NU 47
28 NU 48
29 NU 49
30 NU 50
31 NU 51
32 NU 52
33 NU 53
34 NU 54
35 NU 55
36 NU 56
37 NU 57
38 NU 58
39 DAI0_PIN19 59
40 DAI1_PIN19 60
Pin Signal Pin
21 OSPI_D7 41
Signal Pin
DAI0_PIN20 61
DAI1_PIN20 62
GND3 63
GND4 64
GND5 65
GND6 66
NU 67
NU 68
NU 69
NU 70
NU 71
NU 72
NU 73
NU 74
GND7 75
GND8 76
NU 77
NU 78
NU 79
NU 80
Signal Pin Signal
TWI2_SDA 61 NU
Signal Pin Signal
NU 81 GPIO3
NU 82 NU
NU 83 GPIO4
NU 84 GPIO6
NU 85 GPIO5
NU 86 GPIO7
NU 87 GND9
NU 88 GPIO8
NU 89 NU
NU 90 GPIO9
NU 91 NU
NU 92 GPIO10
NU 93 NU
NU 94 GND10
NU 95 NU
NU 96 NU
GPIO1 97 NU
NU 98 NU
GPIO2 99 NU
NU 100 NU
Pin Signal
81 LINKPORT0_D7
Connectors
3–13
