Table 3-10: SoM Interface C Connector (J3) (Continued)
Pin Signal
10 NU
11 NU
12 NU
13 NU
14 NU
15 NU
16 NU
17 NU
18 NU
19 NU
20 NU
Table 3-11: Mating Connector
Part Description
100-pin, 0.64 mm
100-pin, 0.64 mm
®
EV-21569-SOM Manual
Pin Signal
30 NU
31 NU
32 NU
33 NU
34 NU
35 NU
36 GND5
37 NU
38 SYS_CLKOUT
39 GND6
40 AUDIO_CLK
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Pin Signal
50 JTG0_TCK/
SWCLK
51 NU
52 JTG0_TDO/SW0 72
53 NU
54 JTG0_TDI
55 NU
56 JTG0_TRST
57 NU
58 TARGET_RESET 78
59 NU
60 GND9
Part Number
LSS-150-01-L-DV-A-K
LSS-150-01-L-DV-A-K
Pin Signal Pin Signal
70 NU 90 GND12
71 NU 91 VDD_A
NU 92 VDD_DMC
73 NU 93 VDD_INT
74 NU 94 SYS_HWRST
75 NU 95 PWR_SEQ_GOOD
76 GND10 96 SoM_Reset
77 NU 97 VDD1
GPIO1 98 VSS1
79 NU 99 VDD2
80 GPIO2 100 VSS2
