Analog Devices EVAL-KW4502Z User Manual

General Description
The EVAL-KW4502Z is a demonstration board for
evaluating the low-frequency noise of three general
operational amplifiers (op amp): (1) low-power op amp, (2)
low-noise, bipolar op amp, and (3) low-noise, zero-drift op
amp.
The EVAL-KW4502Z uses ADA4510-2, which is a high
precision, low offset voltage, low-noise, rail-to-rail input
and output operational amplifier, as it can operate in low
voltage supplies like ±5V that can be provided by the
ADALM2000 Active Learning Module.
The EVAL-KW4502Z accommodates LT1782, ADA4077,
and ADA4522 in a thin small outline transistor (TSOT),
standard small outline package (SOIC), and mini small
outline package (MSOP), respectively.
Full specifications on the LT1782, ADA4077, and
ADA4522 are available on the Analog Devices, Inc.
website.
Features
•
Enables Quick Measurement of Low-Frequency Noise
(0.1Hz to 10Hz)
•
Evaluates Low-Power, Low-Noise, and Zero-Drift
Amplifiers
•
Accommodates 5-Lead TSOT, 8-Lead SOIC, and 8-
Lead MSOP Packages
•
Easy plugin into ADALM2000 Active Learning Module
Rev 0
O n e A n a l o g W a y , W i l m i n g t o n , M A 0 1 8 8 7 - 2 3 5 6 , U . S . A .
Evaluating Low-Frequency Noise of Operational Amplifiers
Evaluation Kit Contents
•
•
Equipment Needed
•
•
•
Software Needed
•
Documents Needed
•
•
•
•
DOCUMENT FEEDBACK
T e l : 7 8 1 . 3 2 9 . 4 7 0 0
Evaluation Board User Guide
EVAL-KW4502Z
EVAL-KW4502Z evaluation board
2-Pin Mini Jumper Short Circuit Cap
ADALM2000 Active Learning Module
USB-A to Micro-USB Cable
Computer
Scopy Software
ADA4510 Data sheet
LT1782 Data sheet
ADA4077 Data sheet
ADA4522 Data sheet
