Optex AX-330PLUS Installation Instructions Manual page 4

2-3 Terminal and wiring
1
Receiver
ALARM OUTPUT
Form C
(28 VDC 0.2 A max.)
POWER INPUT
10.5 to 28 VDC
COM N.C. N.O. SP
Wiring distance
3
When using two or more units on one wire,
the maximum length is obtained by dividing
the maximum wire length listed right by the
number of units.
(a detector = a receiver or a transmitter. )
The power wire should not exceed that.
3
Beam interruption time adjustment
Beam interruption time adjustment is on the receiver unit. This function allows you to adjust the sensitivity of the device to
fit to surroundings. A slower setting means less sensitivity.
Time adjustment
(Receiver)
Typical
interruption
time setting
Caution
TAMPER
(N.C.)
SPARE
TAMPER
200
Running Jogging
(50 msec) (100 msec)
The speed shown above is the maximum detectable speed for each setting.
Faster speed will not be detected. For cases where birds, newspapers, or
suspended matters may accidentally interrupt the beam, adjust the set value to
a slower speed (longer interruption time).
2
Transmitter
POWER INPUT
10.5 to 28 VDC
Wire size
AWG 22
(0.33 mm ) 2
AWG 20
(0.52 mm ) 2
AWG 18
(0.83 mm )
2
AWG 16
(1.31 mm )
2
200 200
Walk fast
(200 msec)
- 4 -
m (ft.)
12 VDC 24 VDC
500 2 500
(1 600) (8 100)
800 4 000
(2 600) (13 000)
1 200 6 000
(4 000) (19 500)
2 000 10 000
(6 500) (32 500)
200
200
Walk slow
Slow movement
(350 msec)
(500 msec)
