7-3 Alarm signal is being generated though beams are not blocked
START
Is the alarm indicator
LED on the receiver
illuminated?
NO
Go to "7-1" on the
previous page.
7-4 False activations
START
OK
Check alignment voltage
from the monitor jack.
Does it satisfy the
minimum requirement?
NG
Re-align the beams.
Refer to "4. Optical
alignment". on page 5.
Are the units mounted
on a stable footing with
little movement of the
mounting structure?
OK
NG
Change the footing, pole
or structure to insure a
stable mounting surface.
Important
Note;
This device is designed to detect moving objects and trigger alarms to the control panel.
It is only a part of the entire alarm system, and we do not bear the losses or consequences caused by invasions.
■ EU contact information
Manufacturer:
OPTEX CO., LTD.
5-8-12 Ogoto, Otsu, Shiga, 520-0101 JAPAN
Authorized representative in Europe:
OPTEX (EUROPE) LTD.
/ EMEA HEADQUARTERS
Marandaz House 1 Cordwallis Park,
Clivemont Road, Maidenhead, Berkshire,
SL6 7BU U.K.
Check that the "monitor
OK OK
jack output" value shows
3.0 VDC or above to
insure the beams are
properly aligned.
.
NG
Re-align the beams using a volt meter to insure proper
monitor jack output voltage. Does the value satisfy the
beams requirement?
NO
Is the LED indicator on the transmitter on?
There is frost or snow on the unit's cover.
Very heavy rain occured at the same time as the activation.
There are plants, trees or debris that may block the beam
during windy conditions.
The unit may be detecting a large bird.
The units may be detecting small animals.
(dog, cat, deer etc...)
The receiver is facing directly at the rising or setting sun.
There are reflective objects within 1 m (3 feet) of beam
path. (cars, glass, surfaces with high gloss paints etc.)
Bad wiring or corroded splices. Check for shorts, opens,
grounds and high resistance on the alarm circuit wires.
The covers are very dirty or dusty.
The majority of false activations can be attributed to poor beam alignment.
When aligning the outdoor beams, accept the value of no less than
the "EXCELLENT" value for the most stable and trouble free system.
Refer to the Installation Instructions for acceptable monitor jack voltage values.
