Inserting the Power Cord to AC Power Socket: 1. Insert the power cable plug directly into the AC

Socket located at the back of the switch. 2. Plug the other end of the cable into a grounded, 3-Pin, AC

power source. 3. Check the front-panel LEDs as the device is powered on to be sure the POWER LED

is lit. If not, check that the power cable is correctly plugged in. Warning: For International use, you may

need to change the AC line cord. You must use a line cord set that has been approved for the socket

type in your country. See the Install Guide.

The default values of the managed switch are IP Address = 192.168.1.77, Subnet Mask =

255.255.255.0, Default Gateway = 192.168.1.254, Username = admin, and Password

After the managed switch has been configured in the CLI via the switch's serial interface, you can

browse it. For instance, type

displays (see below) prompting you for a username and password for login and access authentication.

The default username and password are both "admin". For first time use, enter the default username

and password, then click the <Login> button. The login process is complete.

When the login process is complete, the SM24T6DPA web GUI displays

These manuals describe the switch management functions: SM24T6DPA Install Guide (33664), User

Guide (33666), and CLI Reference (33665). To access the manuals, firmware, datasheet or other

documentation for your product, enter model number SM24T6DPA in the "Search" box at our website

https://www.transition.com/.

Transition Networks * 10900 Red Circle Drive * Minnetonka, MN 55343 USA *

33670 Rev. B

http://192.168.1.77

in the address row in a browser; the Login screen

https://www.transition.com/

SM24T6DPA Quick Start Guide

= admin.
