Installation
Warnings
·
Make sure the camera's power cable is properly connected. All electrical work must be performed in
accordance with local regulatory requirements.
·
Use a UL Listed Power Adapter that meets LPS (Limited Power Source) requirements.
·
Note the camera's maximum power consumption:
Idle
Motor + camera on
Cold start only heater (camera off)
IR LED + camera on
IR LED + camera on + motor
IR + heater + camera on
IR + heater + motor + camera on
24 VAC (W)
PoE (W)
·
A PoE injector should be connected only to a PoE network inside a building and not routed outside the
building.
·
If the camera is installed outdoors with an external power supply, the power supply must be installed
with proper weatherproofing.
·
A qualified service person should install the camera.
