SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, DMX and EtherNet/IP.
By Pressing the
"Set
Communication" button from the main window of SW674-A026 (Fig. 2) the
window "Set Communication" appears (Fig. 3).
The meaning of the fields of "EtherNet/IP" are:
In the field
"IP
ADDRESS" the IP address of the EtherNet/IP side of the converter is defined;
In the field
"SUBNET
defined;
In the field "GATEWAY" the default gateway of the network is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out of the net;
In the field "Port" the port used for EtherNet/IP communication is defined (fixed to '44818').
The means of the fields for the "DMX" section are:
In the field "DMX" it is possible to define if the converter will act as DMX controller ("OUT") or
as DMX device ("IN");
In the field
"Channel
Number" the number of channels of the DMX side is defined (up to 496
channels);
In the field
"Channel
EtherNet/IP data is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Mask" the SubNet Mask of the EtherNet/IP side of the converter is
Start" the starting DMX channel to/from which mapping/taking the
User Manual DMX / EtherNet/IP - Converter
Document code: MN674-A026_ENG
Page 16 of 30
Figure 3: "Set Communication" window
INFO:
www.adfweb.com
Revision 1.000 Page 16 of 30
