Industrial Electronic Devices

User Manual

Revision 1.000

English

Modbus Slave / SNMP Manager –

Converter

(Order Code: HD674-A010)

For Website information:

www.adfweb.com?Product=HD674-A010

For Price information:

www.adfweb.com?Price=HD674-A010

Benefits and Main Features:

Very easy to configure

Wide supply input range

Electrical isolation

Industrial temperature range:

-40°C / 105°C (-40°F / 221°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

Axis Solutions Pvt Ltd is the Authorized Distributor of

www.axisindia.in | info@axisindia.in

User Manual Modbus Slave / SNMP Manager

Document code: MN674-A010_ENG

Page 1 of 32

For others Gateways / Bridges:

J1939 to Modbus

Need help?

Do you have a question about the HD674-A010 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD674-A010

Page 1 Page 1 of 32 Industrial Electronic Devices User Manual Revision 1.000 English Modbus Slave / SNMP Manager – Converter (Order Code: HD674-A010) For others Gateways / Bridges: For Website information: www.adfweb.com?Product=HD674-A010 J1939 to Modbus See also the following links: For Price information: www.adfweb.com?Product=HD67212...
Page 2 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 2 of 32 Page 2 of 32 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION...
Page 3 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 3 of 32 Page 3 of 32 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 4 of 32 Page 4 of 32 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 5 of 32 Page 5 of 32 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD674-A010-2-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 6 of 32 Page 6 of 32 Industrial Electronic Devices Figure 1b: Connection scheme for HD674-A010-2-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 7 of 32 Page 7 of 32 Industrial Electronic Devices Figure 1c: Connection scheme for HD674-A010-4-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 8 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 8 of 32 Page 8 of 32 Industrial Electronic Devices Figure 1d: Connection scheme for HD674-A010-4-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 9 Industrial Electronic Devices CHARACTERISTICS: The “HD674-A010” series are rugged devices used to interface SNMP devices with a Modbus network. With its particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal, vertical, oblique).
Page 10 POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD674-A010-Exx-xx Consumption at 24V DC: Device W/VA HD674-A010-Exx-xx Caution: Not reverse the polarity power HD674-A010-E4x-xx HD674-A010-E7x-xx Note: It is possible to use also negative tensions.
Page 11 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 11 of 32 Page 11 of 32 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below.
Page 12 Page 12 of 32 Industrial Electronic Devices RS232: The connection of the RS232 in the HD674-A010-2-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page.
Page 13 Industrial Electronic Devices RS485: The connection of the RS485 in the HD674-A010-4-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page. The connection of the RS485 in the HD67-A010-4-E7x-xx device must be made with a AMP SuperSeal 1.5 Male connector.
Page 14 ETHERNET: The connection of Ethernet in the HD674-A010 device must be made with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
Page 15 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 15 of 32 Page 15 of 32 Industrial Electronic Devices USE OF COMPOSITOR SW674-A010: To configure the Converter, use the available software that runs with Windows called SW674-A010. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 16 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 16 of 32 Page 16 of 32 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “Modbus Slave / SNMP Manager - Converter”...
Page 17 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 17 of 32 Page 17 of 32 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 18 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 18 of 32 Page 18 of 32 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
Page 19 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 19 of 32 Page 19 of 32 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, Modbus and SNMP. By Pressing the “Set Communication”...
Page 20 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 20 of 32 Page 20 of 32 Industrial Electronic Devices SNMP MANAGER: Figure 4: “Set SNMP Manager Access” window By Pressing the “SNMP Manager” button from the main window for SW674-A010 (Fig. 2) the window “Set SNMP Manager Access” appears (Fig.
Page 21 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 21 of 32 Page 21 of 32 Industrial Electronic Devices In the field “Num Bytes” it is possible to select define the dimension of the SNMP Data; In the field “Conversion”...
Page 22 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 22 of 32 Page 22 of 32 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Connect the USB cable;...
Page 23 A010 device. Note: When you receive the device, for the first time, you also have to update the Firmware in the HD674-A010 device. Warning: If Fig. 6 appears when you try to do the Update try these points before seeking assistance: Try to repeat the operations for the updating;...
Page 24 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 24 of 32 Page 24 of 32 Industrial Electronic Devices MODBUS MAP: On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps. Read with Input Register / Status Function not enabled Data in reading: Type...
Page 25 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 25 of 32 Page 25 of 32 Industrial Electronic Devices Read with Input Register / Status Function enabled Data in reading: Type Address Function Description “Position” 0-1 (data read from SNMP) Input Register “Position”...
Page 26 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 26 of 32 Page 26 of 32 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 27 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 27 of 32 Page 27 of 32 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 28 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 28 of 32 Page 28 of 32 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 29 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 29 of 32 Page 29 of 32 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 30 4: MiniFit 7: SuperSeal 1.5 Enclosure Type E: Metal enclosure Device Family HD674-A010 = Modbus Slave / SNMP Managera - Converter ACCESSORIES: Order Code: AC34001 Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 Rail DIN - Power Supply 110V AC 50/60Hz –...
Page 31 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 31 of 32 Page 31 of 32 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 32 User Manual Modbus Slave / SNMP Manager Document code: MN674-A010_ENG Revision 1.000 Page 32 of 32 Page 32 of 32 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
