ADF Web AXIS HD674-A007 User Manual

Profinet/modbus slave - converter

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Industrial Electronic Devices

User Manual

Revision 1.000

English

PROFINET / Modbus Slave – Converter

(Order Code: HD674-A007)

For Website information:

www.adfweb.com?Product=HD674-A007

For Price information:

www.adfweb.com?Price=HD674-A007

Benefits and Main Features:

Very easy to configure

Wide supply input range

Electrical isolation

Industrial temperature range:

-40°C / 105°C (-40°F / 221°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

Axis Solutions Pvt Ltd is the Authorized Distributor of

www.axisindia.in | info@axisindia.in

User Manual PROFINET / Modbus Slave

Document code: MN674-A007_ENG

Page 1 of 34

For others Gateways / Bridges:

J1939 to Modbus

Need help?

Do you have a question about the AXIS HD674-A007 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web AXIS HD674-A007

Page 1 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 1 of 34 Page 1 of 34 Industrial Electronic Devices User Manual Revision 1.000 English PROFINET / Modbus Slave – Converter (Order Code: HD674-A007) For Website information: www.adfweb.com?Product=HD674-A007 For others Gateways / Bridges: For Price information: J1939 to Modbus...
Page 2: Updated Documentation
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 2 of 34 Page 2 of 34 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...
Page 3: Security Alert
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 3 of 34 Page 3 of 34 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Example Of Connection
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 4 of 34 Page 4 of 34 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 5 of 34 Page 5 of 34 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD674-A007-2-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 6 of 34 Page 6 of 34 Industrial Electronic Devices Figure 1b: Connection scheme for HD674-A007-2-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 7 of 34 Page 7 of 34 Industrial Electronic Devices Figure 1c: Connection scheme for HD674-A007-4-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 8 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 8 of 34 Page 8 of 34 Industrial Electronic Devices Figure 1d: Connection scheme for HD674-A007-4-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 9 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 9 of 34 Page 9 of 34 Industrial Electronic Devices CHARACTERISTICS: The “HD674-A007” series are rugged devices used to interface Modbus Master with PROFINET network. With its particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal, vertical, oblique).
Page 10: Power Supply
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 10 of 34 Page 10 of 34 Industrial Electronic Devices POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below.
Page 11 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 11 of 34 Page 11 of 34 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 12 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 12 of 34 Page 12 of 34 Industrial Electronic Devices RS232: The connection of the RS232 in the HD674-A007-2-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page.
Page 13 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 13 of 34 Page 13 of 34 Industrial Electronic Devices RS485: The connection of the RS485 in the HD674-A007-4-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page. The connection of the RS485 in the HD67-A007-4-E7x-xx device must be made with a AMP SuperSeal 1.5 Male connector.
Page 14 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 14 of 34 Page 14 of 34 Industrial Electronic Devices ETHERNET: The connection of Ethernet in the HD674-A007 device must be made with at least a Category 5E cable. The maximum length of the cable should not exceed 100m.
Page 15 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 15 of 34 Page 15 of 34 Industrial Electronic Devices USE OF COMPOSITOR SW674-A007: To configure the Converter, use the available software that runs with Windows called SW674-A007. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 16: New Configuration / Open Configuration
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 16 of 34 Page 16 of 34 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “PROFINET / Modbus Slave - Converter”...
Page 17: Software Options
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 17 of 34 Page 17 of 34 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 18: Set Communication
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 18 of 34 Page 18 of 34 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, Modbus and PROFINET. By Pressing the “Set Communication”...
Page 19 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 19 of 34 Page 19 of 34 Industrial Electronic Devices PROFINET XML: By Pressing the “PROFINET XML” button from the main window for SW674-A007 (Fig. 2) it is possible to generate the xml file to be imported into the master PROFINET.
Page 20: Update Device
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 20 of 34 Page 20 of 34 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device;...
Page 21 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 21 of 34 Page 21 of 34 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD674- A007 device.
Page 22: Modbus Map
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 22 of 34 Page 22 of 34 Industrial Electronic Devices MODBUS MAP: On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps. Read with Input Register / Status Function not enabled Data in reading: Type...
Page 23 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 23 of 34 Page 23 of 34 Industrial Electronic Devices Read with Input Register / Status Function enabled Data in reading: Type Address Function Description Input Bytes 0-1 of PROFINET side Input Register Input Bytes 2-3 of PROFINET side Input Register...
Page 24: Plc Configuration
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 24 of 34 Page 24 of 34 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the PROFINET Converter as described on the following pages was accomplished with the help of the TIA Portal V12-software by Siemens.
Page 25 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 25 of 34 Page 25 of 34 Industrial Electronic Devices 2) Import the module in the network; connect the device to the PLC network and edit the parameters of IP, station name etc. ADFweb.com Srl –...
Page 26 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 26 of 34 Page 26 of 34 Industrial Electronic Devices 3) Load the configuration into the PLC. ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 27: Mechanical Dimensions
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 27 of 34 Page 27 of 34 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 28 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 28 of 34 Page 28 of 34 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 29 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 29 of 34 Page 29 of 34 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 30 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 30 of 34 Page 30 of 34 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 31: Ordering Informations
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 31 of 34 Page 31 of 34 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD674-A007 – x - E y z – s f Fixing lugs A: Type A B: Type B...
Page 32 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 32 of 34 Page 32 of 34 Industrial Electronic Devices ACCESSORIES: Order Code: AC34001 Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 Rail DIN - Power Supply 110V AC 50/60Hz –...
Page 33 User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 33 of 34 Page 33 of 34 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 34: Warranties And Technical Support
User Manual PROFINET / Modbus Slave Document code: MN674-A007_ENG Revision 1.000 Page 34 of 34 Page 34 of 34 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
