SET COMMUNICATION:

This section defines the fundamental communication parameters of two buses, CAN and Modbus.
By pressing the "Set Communication" button from the main window for SW67412 (Fig. 2) the
window "Set Communication Setting" appears (Fig. 3).
The meaning of the fields of "CAN" are:
In the field "Baudrate" the data rate of the CAN bus is defined;
In the field "TimeOut
frames is defined;
In the field "Modbus Register
the CAN communication is defined. '1' means that the communication is good and '0' means
that at least one CAN frame is not received into the timeout defined;
If the field "Enable Write CAN on
are sent when a specific Modbus register is written by the Master.
The meaning of the fields of "Modbus Slave" are:
In the field "Baudrate" the data rate of the RS485 bus is defined;
In the field "Parity" the serial parity is defined;
In the field "ID Device" the Modbus ID is defined;
If the field "Cancel Data after
will be erased after the Modbus reading request;
If the field "Not Cancel if read Input
in reception are not erased if the Modbus function 04 is used.
ADFweb.com Srl – IT31010 – Mareno – Treviso
(seconds)" the maximum time that the device attends for the CAN
TO" the value of Modbus register in which saving the status of
Request" is checked, the CAN messages in transmission
Read" is checked, the data for the CAN messages in reception
Registers" is checked, the data for the CAN messages
User Manual CAN / Modbus Slave - Converter
Document code: MN67412_ENG Revision 2.101
Figure 3: "Set Communication"
