STEP 3
STABILIZER RAIL INTO SIDE RAIL PANEL
ASSEMBLY
STEP 3.1
On inside face of both side panels are pre-installed metal
brackets, designed to hold the stabilizer rails. Set both ends of
the stabilizer rails into brackets, as illustrated in DETAIL D.
STEP 3.2
Once the stabilizer rails are set, gently tilt the crib as
illustrated in DETAIL E, then fasten the stabilizer rails with
bolt together with plain washer and lock washer provided, as
illustrated in DETAIL F.
HARDWARE NEEDED FOR STEP 3
(CC) 1/4" x 13/16 " Allen Bolt = 4 pcs
Lock Washer = 4 pcs
Plain Washer = 4 pcs
Allen Wrench = 1 pc
DETAIL D
DETAIL E
DETAIL F
8/11
