Made in Vietnam
Distributed in the U.S.A. by:
Restoration Hardware Baby & Child
10640 Harrel St. Suite B
Mira Loma, CA 91752
www.rhbabyandchild.com
Distributed in Canada by:
Restoration Hardware Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia V6E4N7
WARNING: Read all instructions before
assembling this product. KEEP
INSTRUCTIONS FOR FUTURE USE.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to the address above. Include the
product model number, color, and a brief description of the part. Call 1-800-762-1751.
C ARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. Dust often using a clean, soft, dry cloth. Blot spills immediately and wipe
with a clean damp cloth. If the crib is to be stored, store in a cool dry place and carefully package all original hardware to protect from loss.
TOOLS AND INSTALLATION
Tools Necessary: Allen Key (included)
NOTE: It may be easier to assemble product with two people.
NOTE: When inserting bolts, turn clockwise until tight. Then loosen
completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly
1
3
-
of a turn. After crib is
2
4
Page 1 of 10
Advertisement
Related Manuals for RH Baby&child ALEXANDRA TUFTED CRIB
Summary of Contents for RH Baby&child ALEXANDRA TUFTED CRIB
- Page 1 Made in Vietnam Distributed in the U.S.A. by: Restoration Hardware Baby & Child 10640 Harrel St. Suite B Mira Loma, CA 91752 www.rhbabyandchild.com Distributed in Canada by: Restoration Hardware Canada, Inc. 1500-1055 West Georgia Street Vancouver, British Columbia V6E4N7 WARNING: Read all instructions before assembling this product.
- Page 2 IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING nfants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant. WARNING: Failure to follow these warnings and the assembly instructions could result in serious injury or death. To reduce the risk of SIDS, pediatricians recommend healthy infants be placed on their backs to sleep, unless otherwise advised by your physician.
- Page 3 IMPORTANT SAFETY INFORMATION FOR CRIBS CAUTION: ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES WITH A THICKNESS NOT EXCEEDING 6 INCHES. WARNING Do not use this crib if the enclosed or attached instructions ●...
- Page 4 IMPORTANT SAFETY INFORMATION FOR TODDLER & DAY BEDS WARNING: ENTRAPMENT / STRANGULATION HAZARD Infants have died in toddler beds from entrapment and strangulation. Failure to follow these warnings and the assembly instructions could result in serious injury or death. NEVER use bed with children under 15 months. NEVER place bed near windows where cords from blinds or drapes may strangle a child.
-
Page 5: Item Identification
ITEM IDENTIFICATION For ease of identification, all parts are labeled to correspond to the Step number in which the part is used. Step #1 First side rail and end panel assembly (Page 6) Step #2 Mattress Support Arm assembly Stabilizer Rail assembly Mattress height adjustment (Page 7) Step #3 Installation of Stabilizer Rail into the end panels (Page 8) Step #4 Second side rail assembly (Page 9) - Page 6 STEP #1 1ST SIDE RAIL & END PANEL ASSEMBLY Attach the the first side rail to the end panels by using Allen bolts (AA), lock washers and plain washers. See Detail A. HARDWARE NEEDED FOR STEP #1: (AA) 1/4" X 1-3/4" BOLT = 4 PCS DETAIL A LOCK WASHERS 1/4"...
- Page 7 STEP #2 MATTRESS SUPPORT ARM ASSEMBLY DETAIL B STABILIZER RAIL ASSEMBLY MATTRESS HEIGHT ADJUSTMENT LOCK HEX NUT STEP #2.1 WASHER Lay Mattress Support flat with Stabilizer Rail on each side. NOTE: On each end of the arm of the Mattress Support, there is a hole for the ALLEN BOLT bolt to pass through that corresponds to the holes located in the frame of (BB)
- Page 8 STEP #3 INSTALLATION OF STABILIZER RAILS INTO THE END PANELS STEP #3.1 On inside surface of both end panels are pre-installed metal brackets, designed to hold the Stabilizer Rails. Set both ends of the Stabilizer Rails into brackets, as illustrated in DETAIL D.
- Page 9 STEP #4 2ND SIDE RAIL ASSEMBLY Attach the second side rail to the end panels by using Allen bolts (AA), lock washers and plain washers. See Detail F. After assembly, re-tighten all bolts to a snug fit. DO NOT OVER TIGHTEN. HARDWARE NEEDED FOR STEP #4: (AA) 1/4"...
- Page 10 STEP #5 TODDLER RAIL ASSEMBLY ALLEN BOLT Ø1/4" X 1/2" STEP #5.1: Remove the front rail panel of the crib by loosening all the bolts installed. STEP #5.2: DETAIL G Gently tilt the crib and release the bolts underneath the metal brackets holding the stabilizer rails.
