Page 2
IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING: Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant. WARNING: Failure to follow these warnings and the assembly instructions could result in serious injury or death. ·...
Page 3
IMPORTANT SAFETY INFORMATION FOR CRIBS CAUTION: ANY MATTRESS USED IN THIS CRIB SHALL BE AT LEAST 27 1/4" X 51 5/8" WITH A THICKNESS NOT EXCEEDING 6". WARNING Do not use this crib if you cannot exactly follow the instructions provided.
Page 4
IMPORTANT SAFETY INFORMATION FOR TODDLER AND DAYBEDS WARNING: ENTRAPMENT / STRANGULATION HAZARD Infants have died in toddler beds from entrapment and strangulation. Failure to follow these warnings and the assembly instructions could result in serious injury or death. NEVER use bed with children under 15 months of age. NEVER place bed near windows where cords from blinds or drapes may strangle a child.
ITEM IDENTIFICATION For ease of identification, all parts are labeled to correspond to the Step number in which the part is used. Step #1 First side rail and end panel assembly (Page 6) Step #2 Mattress Support Arm assembly Stabilizer Rail assembly Mattress height adjustment (Page 7) Step #3 Installation of Stabilizer Rail into the end panels (Page 8)
Page 6
STEP #1 1ST SIDE RAIL & END PANEL ASSEMBLY Attach the the first side rail to the end panels by using Allen bolts (AA) with the lock washers and plain washers. Please see DETAIL A. HARDWARE NEEDED FOR STEP #1: (AA) 1/4"...
Page 7
STEP #2 MATTRESS SUPPORT ARM ASSEMBLY STABILIZER RAIL ASSEMBLY MATTRESS HEIGHT ADJUSTMENT Hexagon nut Lock washer STEP #2.1 Lay Mattress Support flat with Stabilizer Rail on each side Note: On each end of the arm of the Mattress Support, there is a hole for the Mattress bolt bolt to pass through that corresponds to the holes located in the frame of the Mattress Support.
Page 8
STEP #3 INSTALLATION OF STABILIZER RAILS INTO THE END PANELS DETAIL D STEP #3.1 On inside surface of both end panels are pre-installed metal brackets, designed to hold the Stabilizer Rails. Set both ends of the Stabilizer Rails into brackets, as illustrated in DETAIL D.
Page 9
STEP #4 SECOND SIDE RAIL ASSEMBLY Attach the second side rail to the end panels by using Allen bolts (AA), lock washers and plain washers. Please see DETAIL F. After assembly, re-tighten all bolts to a snug fit. DO NOT OVER TIGHTEN. HARDWARE NEEDED FOR STEP #4: (AA) 1/4"...
