For ease of identification, all parts are labeled to correspond
Step 1
Side frame and head board assembly (Page 6)
Step 2
Mattress support arm assembly
Stabilizer rail assembly
Mattress height adjustment (Page 7)
Step 3
Support slat & side rail panel assembly (Page 8)
Step 4
Front rail assembly (Page 9)
Step 5
Toddler rail assembly (Page 10)
Step 6
Metal bed frame assembly (Page 11)
FRONT RAIL
MATTRESS SUPPORT
PARTS IDENTIFICATION
to the Step number in which the part is used.
HEAD BOARD
SIDE RAIL PANEL
5/11
