Made in Vietnam
Model No: 355 - 130/46
Distributed in the U.S.A by:
RH Baby&Child
2900 N MACARTHUR DRIVE
TRACY, CA 95376
www.rhbabyandchild.com
Distributed in Canada by:
RH Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia
V6E4N7
W A RN I N G : Re ad a ll
I nstr u ct io ns be for e as s e mb l ing
thi s pro duct .
KEEP IN S TRU CT I O NS F O R
FUTUR E U SE .
1. Read all instructions before assembly crib. Keep instructions for future use.
2. Never use plastic shipping bags or other plastic film as mattress covers because they can cause suffocation.
3. Infants can suffocate in gaps between crib sides and a mattress that is too small.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to
the address above. Include the product model number, color, and a brief description of the part. Or call 1-800-762-1751.
CARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. If the crib is to be stored, store in a cool,
dry place and carefully package all original hardware to protect from loss.
TOOLS AND INSTALLATION
Tools needed: Key Wrench (included).
Two people are recommended for assembly.
When inserting bolts, turn clockwise until tight. Then loosen 1/2-3/4 of a turn. After bed is completely assembled,
return to each bolt and tighten.
C A LLUM C R IB
TODDLER KIT (SOLD SEPARATELY)
Page 1 of 15
Advertisement
Related Manuals for RH Baby&child CALLUM CRIB 355 - 130/46
Summary of Contents for RH Baby&child CALLUM CRIB 355 - 130/46
- Page 1 C A LLUM C R IB Made in Vietnam Model No: 355 - 130/46 Distributed in the U.S.A by: RH Baby&Child 2900 N MACARTHUR DRIVE TRACY, CA 95376 www.rhbabyandchild.com Distributed in Canada by: RH Canada, Inc. 1500-1055 West Georgia Street Vancouver, British Columbia V6E4N7 W A RN I N G : Re ad a ll...
-
Page 2: Fall Hazard
CA LLU M CR IB WAR NING : Inf a n t s c a n s u f f o c a te o n s o f t bed d in g. Ne ve r add a pil lo w or co mf or ter . N ev e r pla ce a dd i ti o n al p a d di n g u n d er a n i n f ant. - Page 3 C A LLUM C R IB ANY M ATT R E SS U SE D I N T H IS C R IB MU S T B E AT L EAST 2 7 1 / 4 CAUT ION: INCHE S BY 5 1 5 / 8 I NCH ES WIT H A T H IC K N E SS N OT E XC E ED I N G 6 INCHES .
- Page 4 C A LLUM C RIB WAR NING : ENTR APME NT/ST RA NGULATION H AZ ARD In fan ts h ave d ied i n toddler beds f ro m en trapme nt and s trangulation. Fa ilure to fol low these warni ngs an d th e ass emb ly ins truc tions cou ld resul t i n s erious injury or deat h .
-
Page 5: Parts Included
CA LLU M CR IB PA RTS IN CLUD ED: HE A DB O ARD/ FO OT BO A RD S TA T I O N ARY SI DE RAI L S MA T T RE SS SU P P O RT S TRE T CH E R BA RS HAR DWAR E IN CLUDE D : ITEM... - Page 6 C A LLUM C R IB ITEM DESCRIPTION QTY. 1 pc. Allen Key 4mm 10mm 1 pc. Multi Wrench 10mm Mattress Bolts 6 x 40mm 4 pcs. Short Bolts 5/16” x 3/4” 2 pcs. Spring Washer 1/4” x 10mm 4 pcs. Flat Washer 1/4”...
-
Page 7: Middle Level
C A LLUM C RIB STEP 1: Note: The Mattress Support (C) should be at the highest level when the child is born. It must be at the lowest level before the child can stand up. Before installing the Mattress Support (C), determine the desired height of the mattress. - Page 8 C A LLUM C RIB STEP 2: Attach the Stretcher Bars (D) into the Headboard/Footboard (A) using Long Bolts (1), Half Moon Washer (2) and tighten with Allen Key (7). Page 8 of 15...
- Page 9 C A LLUM C RIB STEP 3: Attach the Mattress Support (C) to the Stretcher Bars (D) using Mattress Bolts (9), Spring Washer (11) Flat Washer (12), Hex Nut (5), and tighten with Allen Key (7) and Hex Wrench (8). STEP 4: Lay the Stationary Side Rails (B) in between the Headboard/Footboard (A).
- Page 10 CA LLU M CR IB STEP 5: Attach the Stationary Side Rail (B) to the Headboard/Footboard (A) by using Medium Bolts (3) and tighten with Allen Key (7). W A R N I N G : After crib is completely assembled, return to each bolt and tighten to snug fit.
- Page 11 C A LLUM C RIB PA RTS I N C LU D E D : E [1] TOD DL E R R A I L HAR DWAR E IN CLU DE D: ITEM DESCRIPTION QTY. Medium Bolts 5/16” x 50mm 4 pcs.
- Page 12 C A LLUM C R IB STEP 6: Unscrew and remove the 4 bolts on the stationary side rail using Allen Key (14). Then carefully remove stationary side rail from the crib Page 12 of 15...
- Page 13 C A LLUM C RIB STEP 7: If the mattress support is not in the lowest position, unscrew and remove all the tightened bolts from scissor assembly bars to the Mattress Support (C) and move it to the lowest position. Note: The Mattress Support (C) must be at the lowest level for a toddler bed.
- Page 14 C A LLU M C RIB STEP 8: Position the Toddler Rail (E) between the Headboard/Footboard (A). STEP 9: Attach the Toddler Rail (E) to the Headboard/Footboard (A) by using Medium Bolts (13) and tighten with Allen Key (14). Page 14 of 15...
- Page 15 CA LLU M CR IB STEP 10: When converting the crib to toddler bed, the Short Bolts (15) should be inserted in the upper holes of the Headboard/Footboard (A), and tightened with the Allen Key (14). W A R N I N G : After crib is completely assembled, return to each bolt and tighten to snug fit.
