Made in Vietnam
Distributed in the U.S.A. by:
Restoration Hardware Baby & Child
2900 North Macarthur Dr. Tracy,
CA95376, USA
www.rhbabyandchild.com
Distributed in Canada by:
Restoration Hardware Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia V6E4N7
WARNING: Read all
instructions before assembling this
product. KEEP INSTRUCTIONS
FOR FUTURE USE.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to the address above. Include
the product model number, color, and a brief description of the part. Call 1-800-762-1751.
CARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. Dust often using a clean, soft, dry cloth.
Blot spills immediately and wipe with a clean damp cloth. If the crib is to be stored, store in a cool dry place and carefully package all original
hardware to protect from loss.
TOOLS AND INSTALLATION
Tools Necessary: Allen Key (included)
NOTE: It may be easier to assemble product with two people.
NOTE: When inserting bolts, turn clockwise until tight. Then loosen
tighten. Use wax or soap on all bolts to facilitate assembly
All Restoration Hardware cribs are designed to meet the highest safety
standards and comply with all U.S. and Canadian cribs and cradles regulations.
1
3
-
of a turn. After crib is completely assembled, return to each bolt and
2
4
Page 1 of 12
Advertisement
Related Manuals for RH Baby&child VERSAILLES CONVERSION CRIB
Summary of Contents for RH Baby&child VERSAILLES CONVERSION CRIB
- Page 1 All Restoration Hardware cribs are designed to meet the highest safety standards and comply with all U.S. and Canadian cribs and cradles regulations. Made in Vietnam Distributed in the U.S.A. by: Restoration Hardware Baby & Child 2900 North Macarthur Dr. Tracy, CA95376, USA www.rhbabyandchild.com Distributed in Canada by:...
- Page 2 IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING: Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant. WARNING: Failure to follow these warnings and the assembly instructions could result in serious injury or death. ·...
- Page 3 IMPORTANT SAFETY INFORMATION FOR CRIBS CAUTION: ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES WITH A THICKNESS NOT EXCEEDING 6 INCHES. WARNING Do not use this crib if you cannot exactly follow the instructions that come with it.
- Page 4 IMPORTANT SAFETY INFORMATION FOR TODDLER & DAY BEDS WARNING: ENTRAPMENT / STRANGULATION HAZARD Infants have died in toddler beds from entrapment and strangulation. Failure to follow these warnings and the assembly instructions could result in serious injury or death. NEVER use bed with children under 15 months. NEVER place bed near windows where cords from blinds or drapes may strangle a child.
-
Page 5: Item Identification
ITEM IDENTIFICATION For ease of identification, all parts are labeled to correspond to the step number in which the part is used. Step #1 Lower side rail, headboard and footboard assembly (Page 6). Step #2 Installation of upper side rail into the lower side rail assembly (Page 7). Step #3 Installation of upper side rail into the headboard and footboard assembly (Page 8). - Page 6 STEP #1 LOWER SIDE RAIL, HEADBOARD AND FOOTBOARD ASSEMBLY STEP #1.1 Threaded Rod DETAIL A Bring the Headboard and Footboard into upright position. NOTE: On inside lower faces of Headboard and Footboard are holes with pre-installed nuts for the wooden dowels to pass through which correspond with pre-installed wooden dowels on the Lower Side Rail (Left).
- Page 7 STEP #2 INSTALLATION OF UPPER SIDE RAIL INTO DETAIL B THE LOWER SIDE RAIL STEP #2.1 Gently lay both Upper side rails on their backs on a clean and non-abrasive surface. STEP #2.2 Minifix Bolt Fasten the Minifix bolt through pre-installed nuts underneath of Upper side rails.
- Page 8 STEP #3 INSTALLATION OF UPPER SIDE RAIL INTO THE HEADBOARD & FOOTBOARD STEP #3.1 On both ends of the Upper side rail are holes for the bolt to pass through that correspond to the holes on the posts for headboard and footboard with pre-installed nuts.
- Page 9 STEP #4 DETAIL G MATTRESS SUPPORT ARM ASSEMBLY STABILIZER RAIL ASSEMBLY LOCK HEX NUT WASHER MATTRESS HEIGHT ADJUSTMENT STEP #4.1 Lay mattress support flat with stabilizer rail on each side. ALLEN BOLT (BB) NOTE: On each end of the arm of the mattress support, there is a hole for the bolt to pass through that corresponds to the holes located in the frame of PLAIN ALLEN...
- Page 10 STEP #5 INSTALLATION OF STABILIZER RAILS INTO THE HEADBOARD & FOOTBORAD DETAIL I STEP #5.1 On inside face of both Headboard and Footboard are pre-installed metal brackets, designed to hold the stabilizer rails. Set both ends of the stabilizer rails into brackets, as illustrated in DETAIL I.
- Page 11 STEP #6 DETAIL L TODDLER RAILS ASSEMBLY STEP #6.1 Remove the Upper side rails of the crib by loosening all the bolts together with cam lock installed as well as the mattress support. Minifix Bolt STEP #6.2 Gently tilt the crib and release the bolts underneath the metal brackets holding DETAIL M DETAIL N...
- Page 12 STEP #6 TODDLER RAILS ASSEMBLY DETAIL P STEP #6.6 On right end of the toddler rails are holes for the bolt to pass through that correspond to the holes on the posts for headboard with pre-installed nuts. Align and insert the Allen bolts (removed (DD) from step #6.1) in each hole and tighten with Allen wrench provided, as in DETAIL P.
