Note: After a shutdown (Smart Sounddeck 100 disconnected from the mains) it takes up to 90 seconds until the firmware version for the WiFi
module [WIF] and the Chromecast built-in [CCBI] version can be displayed.
Network Info [NWI]
This menu item is used to view all information about the network and related settings of the Sounddeck 100.
The listed items have the following meanings:
• IP Adress [IP]:
• MAC Adress [MAC]:
• Name [NAM]:
• SSID [SSI]:
• WiFi Band [BAN]:
• STS Wireless [WCH]:
To view the network information, do the following:
To enter the menu, press the "M" button.
1
Use the " " or " " button to navigate into the menu System Info [INF] and confirm with the "OK" button
2
Use the " " or " " button to navigate to the menu item Network Info [NWI] and press the "OK" button to confirm. All network informa-
3
tions will then be displayed as a list in case you have a TV connected.
In case you do not have a TV connected to the Sounddeck 100 you can select the specific network information by using the
4
buttons and pressing "OK" to confirm. The network information will then be shown as scroll text in the display. To exit the selected item
press the Menu button "M".
Repeat step 4 until you have all needed informations.
5
To leave the menu item, press the"M" button.
6
Notes: • The IP address and frequency band of the WiFi module (WiFi Band) can only be displayed after the Smart Sounddeck 100 is
connected to your network via WiFi or network cable.
• If the Sounddeck is connected via network cable, it is not possible to display the SSID.
The IP (internet protocol) adress of the WiFi module assigned by the network router.
The Media Access Control adress is a unique, unchangeable identification number of the WiFi module.
The (network)name of the Sounddeck 100 that has been set during the installation process. The default
name is set as Smart Sounddeck 100.
The name of the connected WiFi network.
The current frequency band of the WiFi module.
The current frequency band of the wireless audio module.
