Summary of Contents for Canton Digital Movie 101

  • Page 1 English...

  • Page 2: Table Of Contents

    Welcome to the world of pure music We are delighted that you have chosen a Canton loudspeaker. Our products combine high quality components with many years of development experience and meticulous production methods. In order to get the best out of your loudspeaker you need to observe a few points, as detailed in the Operating Instructions.

  • Page 3: Safety Advice

    English Safety advice Please follow the safety advice when positioning and maintaining your DM system. Choose a level Avoid moisture Avoid vibrations Never touch the power Do not discard in surface cable with wet hands household rubbish Avoid direct sunlight Protect against Do not open housing Ensure correct polarity...
  • Page 4 English Important Safety Instructions CAUTION CAUTION CAUTION Risk of Danger of electric shock. Danger of life! explosion! Do not open! CAUTION: CAUTION: CAUTION: To reduce the risk of fire and electric shock, Replaceable Lithium batteries! Do not ingest battery. Chemical burn hazard. do not open the device.
  • Page 5 English Objects filled with liquids (such as vases) shall not be placed on the apparatus. No naked flame source, such as lighted candles, should be placed on or beside the apparatus. Do not install the apparatus near any heat sources such as radiators, heat registers, stoves, or other apparatus (incl. amplifiers) that produce heat.
  • Page 6 English Important Safety Instructions Notices Do not use force on operating elements, connections and cables. The apparatus may only be operated with the voltage and frequency specified on the apparatus or the name plate. Do not insert any objects or body parts into the apparatus openings. Live components inside the enclosure could get touched and/or damaged.
  • Page 7 English Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. The remote control supplied with this product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death! If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.

  • Page 8: Unpacking

    • 1x optical digital audio cable • Listen to a variety of music • 1x stereo RCA cable • 1x digital RCA cable Installation The Canton Digital Movie should be positioned underneath the screen on a flat surface. Capacity up to 40 kg...

  • Page 9: Setting Up The Remote Control

    Remote control Connection Terminal Connections DM SUB OUT DIGITAL Power Inlet COAXIAL Output – Ext. Subwoofer Input – TV (optical) ANALOG Input – DVD (coaxial) Input – AUX (analogue) SERVICE DIGITAL Jack service (Canton) OPTICAL DM 101 3 4 3...

  • Page 10: Connection

    English Connection Please ensure that all electrical components are switched off before connecting. Your Digital Movie System has three optional inputs. In principle it is enough to connect one of these inputs to your TV and all further devices to your TV. To achieve the best possible sound we recommend that you connect your satellite receiver, Blu-Ray or DVD player directly to the DM system.

  • Page 11: Operation

    English Operation Power – LED shines green Standby – LED shines red DM disconnected from the mains – LED not illuminated (OFF) Mute (muting) MUTE STANDBY Input (signal source selection) Volume (volume control up/down) Play Mode Stereo (ST) – for music Movie (MOV) –...

  • Page 12: Display Indications

    English Display indications The DM system has a multifunctional display that lights up blue for approx. 5 seconds in response to a remote control command. The most important readouts and their meanings are shown below. The standby mode of the DM system is indicated by a red LE D light.
  • Page 13 English Extended sound functions LipSync Act. / Deact. Select installation mode Act. / Deact. Dolby Set maximum volume Act. / deact. voice ® SUB OUT Dynamic function Range Compression (speech intelligibility) Setup functions Sleep timer 15 – 60 min Act. / Deact. automatic Act.

  • Page 14: Extended Sound Functions

    English Extended sound functions The menu for extended sound functions offers you – the chance to correct out-of-synch playback – to activate the output for a wired external subwoofer – to adjust the playback to suit the location – to switch the Dolby function “Dynamic Range Compression” on or off –...
  • Page 15 English for a free-standing DM system e.g. on a sideboard with a flat-screen TV on the wall (factory setting). for a set-up where a flat-screen TV is positioned on top of the DM system. for a set-up where the DM system is in a rack or on a shelf. When the “Sound”...
  • Page 16 English If you briefly press the “Sound” key again, the display switches to Use the “Voice” function to increase the speech intelligibility in the stereo as well as the surround mode. By doing so, you can better understand dialogs (speech) in films with loud effects, for example.

  • Page 17: Playback Via Bluetooth

    – Once confirmed, the connection will be made automatically and will appear as in the display. – If the connection fails the message - Canton DM 101 - will appear. – If the mobile device requires an access code enter 0000. – If appears in the display, your mobile end device is out of range or logged out.

  • Page 18: Setup Functions

    English Setup functions Sleep Timer (SLP) By activating this function the device will switch to Standby after a defined period. Periods of 15, 30, 45 and 60 minutes can be selected as switch-off times. OFF deactivates the function. To set a switch-off time follow the steps below: With the device switched on, press and hold the “Play Mode”...

  • Page 19: Automatic On/Off Function (Aut)

    English Automatic ON/OFF function (AUT) If this function is activated (ON), the device identifies the presence of a signal in the optical input, digital coaxial input or a previously connected BT auxiliary device. When a signal is detected (e.g. by switching on the source device) the DM system turns itself on. If no such signal is detected on the selected input (e.g.

  • Page 20: Eco Standby (Eco)

    English ECO Standby (ECO) When this function is activated (ON), the device automatically goes into standby mode if no signal is detected on the selected input for one hour. When this function is deactivated (OFF), the DM system has to be switched off manually. The device is supplied with this function activated (ON).

  • Page 21: Automatic Selection Of Bt Input (Sel)

    English Automatic selection of BT input (SEL) When this function is activated ( AUT) , the DM system automatically switches to the BT input when it detects an audio signal from a mobile device. When this function is deactivated (MAN) the input must be selected manually. The device is supplied with this function deactivated (MAN).

  • Page 22: Automatic Playback Via Bt (Apl)

    English Automatic playback via BT (APL) If this function is activated, when the DM 101 is switched on via the “Power” button it automatically starts playback on a previously connected auxiliary device with Bluetooth wireless technology. This starts the playback of the last app opened in the mobile device. ®...

  • Page 23: Restore Factory Settings/Reset (Res)

    English Restore factory settings/Reset (RES) With this function (RES) you can restore the DM System to its delivery state (factory settings). To carry out the Reset follow the steps below: Warning: ALL your personalised settings, learned IR codes and coupled mobile devices will be deleted. With the device switched on, press and hold the “Play Mode”...

  • Page 24: Configuration Of Inputs (Inp)

    English Configuration of inputs (INP) In the delivery state all physically available inputs are supplied with a source designation. These are as follows: Optical (OPT) = TV, Coaxial (COA) = DVD, Analog (ANA) = AUX, Bluetooth = BT. You can change the name allocated to a particular input to suit your source device. To ®...

  • Page 25: Ir Learning Function

    MUTE STANDBY remote control for approx. 5 seconds. The display shows a flashing Press the wanted function on the Canton remote control e.g. “Volume +”. Now the display shows the chosen function, e.g. TV remote control Within 20 seconds press the key you wish to allocate to this function on the TV remote control.
  • Page 26 While you are still in the IR learning menu any key on your remote control within 10 seconds, press one of the Input keys on the Canton remote appears briefly in the display to indicate that no control for 3 seconds to access the direct selection menu.

  • Page 27: Ir Delete Function

    English To exit the direct selection menu, press one of the two input keys again for 3 seconds to access the higher level IR learning menu . If you press the “ON/Standby” key for 3 seconds while still in the direct selection menu, the system switches from this menu to the normal mode.

  • Page 28: Troubleshooting

    English Troubleshooting Here is an overview of the most common problems. If you have any further questions please contact your Canton dealer, call our Service Hotline on +49 (0) 6083 287-0 or send us an e-mail at info@canton.de. Problem Possible cause...
  • Page 29 English Problem Possible cause Solution DM system does not Power cable not connected to the power outlet Prepare connection. turn on. and / or DM system The device does not 1. The preset (factory setting) for the AUT 1. Activate the AUT function (ON) (Page 53). switch on automati- function is OFF (disabled).
  • Page 30 English Problem Possible cause Solution DM system hums. 1. Signal cable from source device to DM system 1. Use shorter signal cable. too long (AUX). 2. Signal cable is not shielded or shielding has 2. Exchange the signal cable by a shielded one. been damaged (defective).
  • Page 31 English Problem Possible cause Solution The optical, coaxial or The input has been deactivated. Activate the input as shown in the chapter Configuration of analog input cannot Inputs (see page 58). be selected using the input button. The DM system does 1.

  • Page 32: Technical Specifications

    English Technical Specifications Power supply Virtualizer – Operating voltage 100–240 V – DTS TruSurround – Operating frequency 50/60 Hz – Power consumption ECO Standby = 0.39 W (factory setting) Bluetooth ® – Power consumption AUT Standby approx. 4.8 W – Bluetooth Standard 3.0 (A2DP) ®...

  • Page 33: Declaration Of Conformity

    EU – Declaration of Conformity marking We, Manufacturer / Importer Canton Elektronik GmbH + Co. KG · Neugasse 21–23 · 61276 Weilrod / Niederlauken · Germany confirm and declare under our sole responsibility that the product DM 101 (Virtual-Surroundsound System with 3 Signal Inputs, one Output, and Bluetooth functionality, ®...

  • Page 34: Further Information

    Deutsch English Further Information Information for “normal use” Information about CE labelling All Digital Movie Systems are designed for indoor use and All electrical and electronic equipment sold in the European Union must not be used outdoors or in wet conditions. The devices must carry a CE mark to show that the device in question complies must not be modified or altered in any way.

  • Page 35: Fcc / Ic Advice

    English Caution – Reorient or relocate the receiving antenna. This device complies with Part 15 of the FCC Rules / Industry Canada – Increase the separation between the equipment and receiver. licence-exempt RSS standard(s). Operation is subject to the following –...

  • Page 36: Guarantee

    Fachhändler gekauft wurden. Wenden Sie sich im Schadensfall bitte an ihn oder direkt an den Canton Service. GUARANTEE Above and beyond the legally prescribed warranty period Canton offers a guarantee of 5 years on all its passive loudspeakers. A 2-year guarantee is offered for DM systems and partially active boxes. The guarantee period begins at the time of purchase and only applies to the purchaser.
  • Page 37 English Notes 3 7 1...
  • Page 38 www.canton.de...
