Channel Level [CHL]

At the Channel Level menu you can adjust the volume level of each individual channel in 1dB (1 Decibel) steps between -10dB and +10dB,
where 0dB is the factory setting. For an easier relative volume adjustment between the different speakers, the Sounddeck 100 is equipped
with a test tone generator.
Caution: Before activating the test tone generator, please set the main volume to a level between 20 and 30. The test tone generator is
depending on the main volume level and cannot be increased or decreased within the menu.
For adjusting the relative volume of the different (virtual) speakers, please follow below instructions:
Press the menu button "M" on the remote to enter the menu.
1
Enter the first menu item Speaker Setup [SPS] by pressing "OK".
2
Enter the Channel Level menu [CHL] by pressing "OK".
3
As first item, Test Tone [TON] is selected automatically. Press "OK" if you want to activate the Test Tone generator.
4
Select [ON] to activate the test tone generator using the "+" button, select [OFF] to disable it using the "–" button.
5
Now, the front left speaker generates a pink noise signal. Press M and then the Down key " ", or directly the Down key "
6
left front speaker [FL] from the speaker list.
Use the "+" resp. the "-" button to change the volume level. Go back to the speaker selection list by pressing"OK".
7
In addition to the front left [FL] speaker you can adjust the virtual center speaker [VCE], the front right speaker [FR], the virtual right
8
surround [VSR] and left surround speaker [VSL], as well as the subwoofer [SUB]. The two speakers Top Left [TL] and Top Right [TR] are
grayed out and not selectable. You can find additional information in the description in the "Sub output" and "Wireless speaker pairing"
part.
The speaker selected in the list of speakers by using the " " or " " button plays back the test tone. At your listening position, all speakers
9
should have approximately the same volume level. It is difficult to find the correct volume level for a subwoofer, because of the different
frequency band. Therefore, adjust the Subwoofer value to your preferred level.
To exit the menu item, press the "M" button. The test tone generator will be deactivated automatically.
10
Note: Speakers marked as "Virtual" are physically not available. The corresponding channel is generated by the physically available
speakers and therefore the gain is only "virtually" adjusted.
Speaker Distance [DST]
An adjustment of the distance between the speakers and listening position is needed for a perfect spatial effect, especially in case of
multichannel input signals. Measure and enter the distance between the speakers and your listening position. The distance is adjustable
between 0.0m and 9.9m, in steps of 0.1m, where 3.0m is the factory setting.
22
" to select this
