HDMI CEC [CEC]

Consumer Electronics Control is a cross-market standardized protocol for controlling devices connected to the HDMI® inputs/outputs. The

device is supplied with this function deactivated (OFF). The CEC functions supported by the Smart Sounddeck 100 are:

- One touch Play: By pressing the "Play" button of, for example a Blu-Ray player the Sounddeck switches on automatically and changes to

the corresponding HDMI® input.

- System Standby: With the TV switched on, when you return it to standby mode by pressing the "Power" key the Sounddeck 100 also

goes automatically into standby mode.

Note:Depending on the programming of the TV device, the Sounddeck 100 can also be automatically activated with the TV.

- Volume/Mute: The volume of the Sounddeck 100 can be operated using the Mute and Volume buttons of the TV remote control.

Notes: • Many device manufacturers have developed their own protocols for controlling their devices based on the CEC standard. This can

mean that the functions described above only function partially, or do not function at all.

• In order to avoid conflicts when controlling the Smart Sounddeck 100, the "Volume +/–", "Mute" and "Power" buttons on the TV

remote control should not be learned through the IR Learn function of the Sounddeck when using the CEC function. Delete the

codes where necessary.

To activate/deactivate this function, proceed with the following steps:

To enter the menu, press the "M" button.

Use the

" "

or " " button to navigate into the menu System Setup [SYS] and confirm with the "OK" button.

Use the

" "

or " " button to choose the function HDMI CEC [CEC] and confirm with the "OK" button.

Use the "+" or "-" button to select [OFF] to disable the CEC functionality resp. [ON] to enable it and confirm with the "OK" button.

Press the "M" button to exit this menu item

Note:

Should you assign a name to an input that is already assigned, the input previously assigned with this name will be deactivated

("- - -"). To continue using this input, you must assign a different name. Each source name can be assigned only once.

Note:

Inputs which have been deactivated "- - -" are no longer displayed when selecting the inputs (input buttons

This simplifies the selection of the desired input.

" "

or " ").
