Note: This parameter is only available if a wireless subwoofer is connected to the Sounddeck 100 or if Sub Out is set to Wired [WRD].
Otherwise this menu item is grayed out.
To set the subwoofer's phase to 180 degree resp. back to 0 degree, please do the following:
To enter the menu, press the "M" button.
1
Use the " " or " " button to navigate into the menu System Setup [SYS] and confirm with the "OK" button.
2
Use the " " or " " button select the menu item Sub Phase [PHA] and confirm with the "OK" button..
3
Change the setting using the "+" or "-" key between 0 degree [0] and 180 degree [180] and confirm with the "OK" button.
4
To exit the menu, press the Menu butoon "M".
5

Lipsync [LIP]

The processing of video data in the TV or a videoprojector usually takes longer than the audio signal processing. Lipsync [LIP] allows you to
take corrective action when the sound out of the Sounddeck 100 is not lip-synchronous with the image on the TV. The delay of the audio
signal
reproduced by the speakers can be set from 0 to max. 200ms, in steps of 10ms. 10ms (Milliseconds) = 0.01seconds.
For this, proceed as follows:
To enter the menu, press the "M" button.
1
Use the " " or " " button to navigate to the menu System Setup [SYS] and confirm with the "OK" button.
2
Use the " " or " " button to select the menu item Lipsync [LIP] and confirm with the "OK" button.
3
Change the delay time using the "+" or "-" key to the desired value and confirm with the "OK" button.
4
To exit the menu, press the Menu butoon "M".
5
Note: Because of wirelessly connected speakers the maximum possible delay may be lower than 200ms.

Max Volume [VOL]

You can limit the maximum settable volume with this (protective) function Max Volume in such a way that the sound level (indicated in the
speaker's display) can not be turned up above the set value. You can set the desired volume level from 0 to 70, where 70 represents the maxi-
mum.
This function does not limit the output volume level of the Sounddeck 100 to a certain level but only the selectable volume.
Note:
Based on the audio source and the incoming signal (level), the output volume can be higher or lower.
