Analog Gain [OFS]

In case the playback level of an analog source connected to the Line input [AUX] is higher or lower than the playback level of the used digital
source(s), you may use this function to approximate the volume levels. The playback level of the analog source relating to that of the digital
source(s) can be set in a range from -6dB to +6dB. This half resp. twice the volume level of the factory setting (0dB).
For setting the offset volume level, proceed as follows:
To enter the menu, press the "M" button.
1
Use the " " or " " button to navigate into the menu System Setup [SYS] and confirm with the "OK" button.
2
Use the " " or " " button to select the menu item Input Config [INP] and confirm by pressing "OK".
3
Select the menu item Analog Gain [OFS] using the " " or " " buttons and confirm with the "OK" button.
4
Select the wanted level using the "+" or "-" key to match your analog device.
5
Then press "OK" again to leave the menu item.
6

Input Select [SEL]

If the Input Select function is set to Auto [AUT], the system automatically changes the optical, coaxial, analogue and BT input as soon as the
signal disappears at the currently selected signal input and an input signal is detected at one of the Sounddeck's inputs mentioned before.
If Manual [MAN] is selected, the inputs must be selected manually via the remote control using the " " or " " button.
By default this fuction is deactivated.
To change the Input Select function from Manual [MAN] to Auto [AUT] or contrary, proceed as follows:
To enter the menu, press the "M" button.
1
Use the " " or " " button to navigate into the menu System Setup [SYS] and confirm with the "OK" button.
2
Use the " " or " " button to select the menu item Input Select [SEL] and confirm with the "OK" button.
3
Change the setting using the "+/-" keys and confirm with the "OK" button.
4
Press the "M" button to exit this menu item.
5
Notes: • The input NET is always selected automatically in case of an incoming audio signal!
• If you want the HDMI® inputs to be switched automatically too, please activate the HDMI® CEC function in the same-named
menu.
• To automatically switch from the optical or coaxial digital input to one of the other inputs, the source unit must be switched off.
For analogue Line and Bluetooth® stopping playback is sufficient.
