Transmission Power [Txp]; Rf Channel [Chn] - Canton Smart Sounddeck 100 Operating Instructions Manual

English
Use the " " or " " button to select the item Wireless Reset [WRE] and confirm with "OK". The menu Wireless Reset is displayed and the
3
status indication should show "No", the display shows [NO].
If you want to cancel the reset precedure, press "OK", or press the menu key "M".
4
If you want to perform the reset, select "Reset all" using
5
The OSD shows "Please Wait", the display still shows [YES]. After a few seconds the Sounddeck 100 jumps back to the menu "Wireless
6
Setup".
Press the "M" button to exit this menu item.
7

Transmission Power [TXP]

The wireless audio module of the Sounddeck 100 is by default set to 25% of the maximum transmission power [ECO], according to -6dB. In
most cases this is completely adequate for a stable and non-interrupted wireless connection with Smart speakers and/or a Smart subwoofer
in the same room. In case of connection problems and/or audio dropouts you can increase the transmission power. At Medium setting [MED]
the transmission power is at 50% (-3dB) and at Max at 100% (0dB).
To adjust the transmission power of the wireless audio module please do as follows:
To enter the menu, press the "M" button.
1
Use the " " or " " button to navigate to the menu Wireless Setup [WIS] and confirm with the "OK" button.
2
Use the " " or " " button to select the item Transmission Power [TXP] and confirm with "OK".
3
Select the desired transmission power using the "+" or "–" key and confirm your selection by pressing "OK".
4
ECO = 25% (-6dB)
Press the "M" button to exit this menu item.
5

RF Channel [CHN]

Usually the wireless audio module of the Sounddeck 100 choses a free radio channel in the 5.2GHz resp. 5.8GHz band automatically (AUTO
/ [AUT]). In case you use your WiFi in the 5GHz band too and dropouts in the audio transmission occur, this function gives you the option to
set the radio frequency of the wireless audio module to a specific channel. If you select a different specific channel for your WiFi Router too,
interferences and dropouts should no longer occur.
The selected frequency for the Sounddeck 100 and the router should ideally be as far apart as possible.
The Sounddeck 100 uses the following radio channels:
• 5.2GHz Band: 5.2G-1 = 5180MHz
• 5.8GHz Band: 5.8G-1 = 5736MHz
40
Medium = 50% (-3dB) Max = 100% (0dB).
5.2G-2 = 5210MHz
5.8G-2 = 5762MHz
" " or " " key and press "OK". The display shows [YES].
5.2G-3 = 5240MHz
5.8G-3 = 5814MHz
