ASSEMBLY

• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you fi nish all assembly steps.
• To identify small parts, see page 7.
1. With the help of a second person, slide the Left
Upright (149) onto the Base Frame (56), making
sure that the Upright Coaxial Cable (125) comes
out of the bottom of the bracket (A) on the Base
Frame. Do not pinch the Upright Coaxial
Cable.
• Assembly requires the following tools:
one 3/8" hex key
one 7/32" hex key
one Phillips screwdriver
To avoid damaging parts, do not use power tools.
1
A
8
149
125
56
