2.1.2
Pole Mount Kit BOX
Name
Figure
Cover IO
2.2
System Setup
SPC-800 devices install Cover IO
1.
The Base Unit standard product contains SPC-800 device, Cover IO and ARM
screws.
Fix 2 pcs with M5 x 10 screws on the Cover IO screw hole location (Do not fas-
ten screw)
2.
Place Cover IO to product and fasten 2pcs Screws.
3.
Fix 2 pcs with M5 x 10 screws on the other Cover IO screw hole location
The following figure shows an example.
Qty Name
Figure
Pole Mount-
1
ing Black
Screw
13
Qty
4
SPC-800 User Manual
