1.1

Introduction

The SPC-800 series devices with a brand-new ID design can support an all-around
IP65 waterproof casting design with general I/O connectors, with I/O cover all the wir-
ing & cabling can be hidden invisible to ensure reliability & field wire simplicity.
SPC-800 is a hardware-solution based HMI product which supports industrial grade
ARM/VESA mount system and push button extension supported. With the design to
fit in the general industrial equipment, such as Rittal and Bernstein, SPC-800 can be
a ubiquitous HMI in any kind of smart factory and even in the machines. By embed-
ding an Intel® Skylake Core™ i3-6100U 2.3GHz processor (Dual Core), SPC-800
can support advanced graphical performance and easily fit in different applications to
achieve IoT fantasy in the field.
The following are the key features:
15.6" HD (Full HD) / 21.5" Full HD TFT LED LCD display

Intel Skylake Intel® Core™ U-series processor with independent GPU,

advanced graphical performance
16:9 wide screen with PCT multi-touch

Built-in function and home key button used for intuitive UI

Anti-scratch touch surface: 7H hardness

All-round IP65 protection with pole mount supported

Front LED indicator to show operating status

Silicone-Free for enclosure

Supports ARM and VESA Mount

Supports Rittal's CP40 & Bernstein's CS-480 B.flex mounting dimensions

Front USB & Re-set Button to allow easily maintenance

Supports RAFI FS22+ Series Push Buttons (UP to System waterproof IP65)

