hIsc(High scale):
High scale of PV
Note: If the model is CM1-TR, the Lo.Sc(A-02) and
Hi.Sc(A-03) are fixed.
pVzro: Fine Zero Adjustment for
PV display
For Zero & Span of PV, users can get the
"Fine Adjustment" by front key. It's an easy
way to "Just Key-In" the value that the user
wants to show in the current input signal.
pVspn:Fine Span Adjustment for
PV display
It's same function as like as [pVzro].
ZSclr: Clear Fine Zero & Span
Adjustment for PV display
lOcut (Low Cut):
Low Cut the PV
Low Cut set to be +0.50
Present
PV according
to input signal
Value
[ lOcut]
)50
0.50
X1
Low cut
X1
function
-0.50
Low Cut is set for 0.50, if the PV is
from -0.50~+0.50, that display will be 0.
Setting Range
(CM1-RL/CM1-F:-19999~99999)
Shift
設定範圍: -1999~9999
Shift
Setting Range
Shift
Setting Range
none(None): Do not clear the fine
pV.zro(PV.Zro): To clear the fine
pV.spn (PV.SPn): To clear the fine
both(Both): To clear the fine
adjustment of Low and High
&
Setting Range
Shift
Low Cut set to be -0.10
[ lOcut]
-)10
X2
Low cut
function
Low Cut is set for -0.10, if the PV is
under (< = -0.10), that display will be -0.10.
CM1-SERIES
: -1999~9999
Up
Down
Enter
Up
Down
Enter
: -1999~9999
Up
Down
Enter
:
adjustment of Low / High.
adjustment Low.
adjustment High
Enter
Cycle selection
: -1999~9999 counts
Up
Down
Enter
PV according
Present
to input signal
Value
-0.10
11 / 28
