CAN
CAN Communication Terminal: (RJ45 port) follow CAN protocol, for output batteries information.
RS485
R485 Communication Terminal: (RJ45 port) follow RS485 protocol, for output batteries information.
Link Port 0, 1
Link Port 0, 1 Communication Terminal: (RJ45 port) follow RS485 protocol, for communication between
multiple parallel batteries.

Definition of RJ45 Port Pin

No.
1
2
3
4
5
6
7
8

Definition of RJ11 Port Pin

No.
1
2
3
4
19PISV0606
RS485 Pin
--
--
--
--
--
GND
RS485A
RS485B
CAN Pin
--
GND
--
CANH
CANL
--
--
--
RS232 Pin
GND
TXD
RXD
GND
