Conventions

1 Conventions
Table 2 provides the definition of some conventions used in the present document.
Table 2.
Convention
Jumper JP1 ON
Jumper JP1 OFF
Solder bridge SBx ON
Solder bridge SBx OFF SBx connections left open
6/41
ON/OFF conventions
Jumper fitted
Jumper not fitted
SBx connections closed by solder
