Danfoss VLT AutomationDrive FC 301 Instruction Manual page 77

Specifications
525–600 V
Power Bussmann Bussmann
[kW] Type RK1 Type J
0.75– KTS-R-5 JKS-5
1.1
1.5-2.2 KTS-R-10 JKS-10
4 [3] KTS-R15 JKS-15
5 [4] KTS-R20 JKS-20
7.5 KTS-R-25 JKS-25
[5.5]
10 [7.5] KTS-R-30 JKS-30
15 [11] KTS-R-35 JKS-35
20 [15] KTS-R-45 JKS-45
25 [18] KTS-R-50 JKS-50
30 [22] KTS-R-60 JKS-60
40 [30] KTS-R-80 JKS-80
50 [37] KTS-R-100 JKS-100
60 [45] KTS-R-125 JKS-125
75 [55] KTS-R-150 JKS-150
100 KTS-R-175 JKS-175
[75]
Table 8.21 525–600 V, Enclosure Types A, B and C
525–690 V
Power Bussmann
[kW] Type RK1
1.1 KTS-R-5
1.5-2.2 KTS-R-10
4 [3] KTS-R15
5 [4] KTS-R20
7.5 [5.5] KTS-R-25
10 [7.5] KTS-R-30
15 [11] KTS-R-35
20 [15] KTS-R-45
25 [18] KTS-R-50
30 [22] KTS-R-60
40 [30] KTS-R-80
50 [37] KTS-R-100
60 [45] KTS-R-125
75 [55] KTS-R-150
100 [75] KTS-R-175
Table 8.22 525–690 V, Enclosure Types A, B and C
MG33AN22
Instruction Manual
Recommended max. fuse
Bussmann Bussmann Bussmann
Type T Type CC Type CC
JJS-6 FNQ-R-5 KTK-R-5
JJS-10 FNQ-R-10 KTK-R-10
JJS-15 FNQ-R-15 KTK-R-15
JJS-20 FNQ-R-20 KTK-R-20
JJS-25 FNQ-R-25 KTK-R-25
JJS-30 FNQ-R-30 KTK-R-30
JJS-35 - -
JJS-45 - -
JJS-50 - -
JJS-60 - -
JJS-80 - -
JJS-100 - -
JJS-125 - -
JJS-150 - -
JJS-175 - -
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-5 JJS-6
JKS-10 JJS-10
JKS-15 JJS-15
JKS-20 JJS-20
JKS-25 JJS-25
JKS-30 JJS-30
JKS-35 JJS-35
JKS-45 JJS-45
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
JKS-175 JJS-175
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Bussmann SIBA Littelfuse
Type CC Type RK1 Type RK1
LP-CC-5 5017906-005 KLS-R-005
LP-CC-10 5017906-010 KLS-R-010
LP-CC-15 5017906-016 KLS-R-015
LP-CC-20 5017906-020 KLS-R-020
LP-CC-25 5017906-025 KLS-R-025
LP-CC-30 5017906-030 KLS-R-030
- 5014006-040 KLS-R-035
- 5014006-050 KLS-R-045
- 5014006-050 KLS-R-050
- 5014006-063 KLS-R-060
- 5014006-080 KLS-R-075
- 5014006-100 KLS-R-100
- 2028220-125 KLS-R-125
- 2028220-150 KLS-R-150
- 2028220-200 KLS-R-175
Bussmann Bussmann
Type CC Type CC
FNQ-R-5 KTK-R-5
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
- -
- -
- -
- -
- -
- -
- -
- -
- -
Ferraz- Ferraz-
Shawmut Shawmut
Type RK1 J
A6K-5-R HSJ-6
A6K-10-R HSJ-10
A6K-15-R HSJ-15
A6K-20-R HSJ-20
A6K-25-R HSJ-25
A6K-30-R HSJ-30
A6K-35-R HSJ-35
A6K-45-R HSJ-45
A6K-50-R HSJ-50
A6K-60-R HSJ-60
A6K-80-R HSJ-80
8
A6K-100-R HSJ-100
A6K-125-R HSJ-125
A6K-150-R HSJ-150
A6K-175-R HSJ-175
Bussmann
Type CC
LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
-
-
-
-
-
-
-
-
-
