Danfoss VLT AutomationDrive FC 301 Instruction Manual page 74

Specifications
525–600 V
Enclosure
A2
A3
A5
B1
B2
B3
B4
8 8
C1
C2
C3
C4
Table 8.15 525–600 V, Enclosure Types A, B and C
525–690 V
Enclosure
A3
B2/B4
B4/C2
C2/C3
C2
Table 8.16 525–690 V, Enclosure Types A, B and C
72
Power [kW] Recommended
fuse size
0.75–4.0 gG-10
5.5–7.5 gG-10 (5.5)
gG-16 (7.5)
0.75–7.5 gG-10 (0.75–5.5)
gG-16 (7.5)
11–18 gG-25 (11)
gG-32 (15)
gG-40 (18.5)
22–30 gG-50 (22)
gG-63 (30)
11–15 gG-25 (11)
gG-32 (15)
18.5–30 gG-40 (18.5)
gG-50 (22)
gG-63 (30)
37–55 gG-63 (37)
gG-100 (45)
aR-160 (55)
75 aR-200 (75)
37–45 gG-63 (37)
gG-100 (45)
55–75 aR-160 (55)
aR-200 (75)
Power [kW] Recommended
fuse size
1.1 gG-6
1.5 gG-6
2.2 gG-6
3 gG-10
4 gG-10
5.5 gG-16
7.5 gG-16
11 gG-25 (11)
15 gG-32 (15)
18 gG-32 (18)
22 gG-40 (22)
30 gG-63 (30)
37 gG-63 (37)
45 gG-80 (45)
55 gG-100 (55)
75 gG-125 (75)
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Instruction Manual
Recommended
Max. fuse
gG-25
gG-32
gG-32
gG-80
gG-100
gG-63
gG-125
gG-160 (37–45)
aR-250 (55)
aR-250
gG-150
aR-250
Recommended
Max. fuse
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-63
gG-80 (30)
gG-100 (37)
gG-125 (45)
gG-160 (55–75)
Recommended circuit Max trip level [A]
breaker Moeller
PKZM0-25
PKZM0-25
PKZM0-25
PKZM4-63
NZMB1-A100
PKZM4-50
NZMB1-A100
NZMB2-A200
NZMB2-A250
NZMB2-A200
NZMB2-A250
Recommended circuit Max trip level [A]
breaker Moeller
PKZM0-16
-
-
-
-
25
25
25
63
100
50
100
160
250
150
250
16
-
-
-
-
MG33AN22
