Diagnostics and Troubleshoo...
WARNING/ALARM 34, Fieldbus communication fault
The serial communication bus on the communication
option card is not working.
WARNING/ALARM 35, Option fault
An option alarm is received. The alarm is option-specific.
The most likely cause is a power-up or a communication
fault.
WARNING/ALARM 36, Mains failure
This warning/alarm is only active if the supply voltage to
the frequency converter is lost and 14-10 Mains Failure is
NOT set to [0] No Function. Check the fuses to the
frequency converter and mains supply to the unit.
ALARM 37, Phase imbalance
There is a current imbalance between the power units
ALARM 38, Internal fault
7 7
When an internal fault occurs, a code number defined in
Table 7.6 is displayed.
Troubleshooting
Cycle power
Check that the option is properly installed
Check for loose or missing wiring
It may be necessary to contact your Danfoss supplier or
service department. Note the code number for further
troubleshooting directions.
No.
0
256-258
512
513
514
515
516
517
518
519
783
1024-1279
1281
1282
1283
1284
1299
1300
44
Text
Serial port cannot be initialized. Contact your
Danfoss supplier or Danfoss Service Department.
Power EEPROM data is defective or too old
Control board EEPROM data is defective or too
old.
Communication timeout reading EEPROM data
Communication timeout reading EEPROM data
Application-oriented control cannot recognize the
EEPROM data.
Cannot write to the EEPROM because a write
command is on progress.
Write command is under timeout
Failure in the EEPROM
Missing or invalid barcode data in EEPROM
Parameter value outside of min/max limits
A CAN message that has to be sent could not be
sent.
Digital signal processor flash timeout
Power micro software version mismatch
Power EEPROM data version mismatch
Cannot read digital signal processor software
version
Option SW in slot A is too old
Option SW in slot B is too old
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Instruction Manual
No.
1301
1302
1315
1316
1317
1318
1379
1380
1381
1382
1536
1792
1793
1794
1795
1796
2049
2064-2072
2080-2088
2096-2104
2304
2305
2314
2315
2316
2324
2325
2326
2327
2330
2561
2562
2816
Text
Option SW in slot C0 is too old
Option SW in slot C1 is too old
Option SW in slot A is not supported (not allowed)
Option SW in slot B is not supported (not allowed)
Option SW in slot C0 is not supported (not
allowed)
Option SW in slot C1 is not supported (not
allowed)
Option A did not respond when calculating
platform version
Option B did not respond when calculating
platform version
Option C0 did not respond when calculating
platform version.
Option C1 did not respond when calculating
platform version.
An exception in the application-oriented control is
registered. Debug information written in LCP.
HW reset of DSP
Motor-derived parameters not transferred correctly
to DSP
Power data not transferred correctly at power-up
to DSP
The DSP has received too many unknown SPI
messages
RAM copy error
Power data restarted
H081x: Option in slot x has restarted
H082x: Option in slot x has issued a power-up wait
H983x: Option in slot x has issued a legal power-
up wait
Could not read any data from power EEPROM
Missing SW version from power unit
Missing power unit data from power unit
Missing SW version from power unit
Missing lo_statepage from power unit
Power card configuration is determined to be
incorrect at power-up
A power card has stopped communicating while
line power is applied
Power card configuration is determined to be
incorrect after the delay for power cards to
register.
Too many power card locations have been
registered as present.
Power size information between the power cards
does not match.
No communication from DSP to ATACD
No communication from ATACD to DSP (state
running)
Stack overflow control board module
