Specifications
Type Designation
1)
High/Normal Overload
Typical Shaft Output [hp] [kW]
Enclosure IP20
Enclosure IP21, IP55, IP66
Output current
Continuous (3 x 525–550 V) [A]
Intermittent (3 x 525–550 V) [A]
Continuous (3x551–600 V) [A]
Intermittent (3x551–600 V) [A]
Continuous kVA (550 V AC) [kVA]
Continuous kVA (575 V AC) [kVA]
Max. input current
Continuous at 550 V [A]
Intermittent at 550 V [A]
Continuous at 575 V [A]
Intermittent at 575 V [A]
Additional specifications
IP20 max. cable cross-section for line power and
2
motor [mm ] ([AWG])
IP20 max. cable cross-section for brake and load
2
sharing [mm ] ([AWG])
IP21, IP55, IP66 max. cable cross-section for line power
and motor [mm 2 ] ([AWG])
IP21, IP55, IP66 max. cable cross-section for brake and
2
load sharing [mm ] ([AWG])
Max cable cross-section 4) for line power disconnect
[mm 2 ] ([AWG])
Estimated power loss at rated max. load hp [W]
Efficiency 2)
Table 8.9 Line Power Supply 3x525–600 V AC (FC 302 only), P37K-P75K
MG33AN22
Instruction Manual
P37K
HO NO
50 [37] 60 [45] 60 [45]
C3 C3
C1 C1
54 65
81 72
52 62
78 68
51.4 61.9 61.9
51.8 61.7 61.7
49 59
74 65
47 56
70 62
50 (1)
50 (1)
50 (1)
50 (1)
50, 35, 35
(1, 2, 2)
3) 1.216 1.216
1.00 [740]
[900] [900]
0.98
