Decoded output
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Decoded Output

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCANTEAM 3210 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Welch Allyn SCANTEAM 3210 Series

Summary of Contents for Welch Allyn SCANTEAM 3210 Series

  • Page 1 Decoded Output...
  • Page 2 E 1998 Welch Allyn, Inc. All rights reserved.
  • Page 3 Welch Allyn reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult Welch Allyn to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Welch Allyn.
  • Page 4 Consult the dealer or an experienced radio or television technician for help. Caution: Any changes or modifications made to this device that are not expressly approved by Welch Allyn, Inc. may void the user’s authority to operate the equipment. Note: To maintain compliance with FCC Rules and Regulations, cables connected to this device must be shielded cables, in which the cable shield wire(s) have been grounded (tied) to the connector shell.
  • Page 5 The Lodge, Tanners Lane Warrington, Cheshire WA2 7NA England Welch Allyn shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.

  • Page 6: Section Page

    TABLE OF CONTENTS Chapter 1 Getting Started Section Page 1.1 Introduction to the 3210 ....1–1 1.2 Unpacking the Scanner ..... 1–2 1.3 Scanner Identification .

  • Page 7: Table Of Contents

    Chapter 3 Additional Programming Selections Section Page 3.1 Introduction ....... 3–1 Programming Instructions .
  • Page 8 Chapter 3 Additional Programming Selections, continued... Section Page 3.5 Retail Symbology Programming ... . . 3–48 UPC Selection ......3–49 EAN Selection .
  • Page 9 Chapter 5 Product Specifications and Pinouts Section Page 5.1 Environmental Specifications ....5–1 5.2 Electrical Specifications ....5–1 5.3 Scanner Performance .
  • Page 10 GETTING STARTED 1.1 Introduction to the 3210 The SCANTEAM 3210 Series Hand Held CCD is durable and reliable, easy to hold and easy to aim. Featuring a unique optics design without moving parts or a glass mirror. Available with Instant Interface decoding, the 3210 supports PC/XT, AT, and PS/2 keyboard wedges, RS–232, and wand emulation.
  • Page 11 1.2 Unpacking the Scanner Open the carton. The shipping carton should contain: SCANTEAM 3210 SCANTEAM 3210 Hand Held CCD Scanner Operating Guide and Programming Menu Shipping Carton Check to make sure everything you ordered is present. Keep the shipping carton to return the scanner for servicing.
  • Page 12 1.3 Scanner Identification SCANTEAM 3210 Identification Label Scan Rate D = 50 Scans/Second ITEM# 3210/D–13 Trigger Option 0 = Auto Trigger 1 = Manual Trigger Interface with Attached Cable Option Option Interface Cable PC XT/AT DIN/DIN on Y Cable PC AT/PS2 Mini-Din/Mini-Din on Y Cable RS-232 9 Pin Female D with External Power Mini-Din...
  • Page 13 1.4 Connecting the Scanner Install the scanner by following the steps shown below: Disconnect power to the terminal/computer by turning the host system power switch to the “OFF” position. Power OFF Connect the interface cable to the scanner and to the terminal/computer.
  • Page 14 Once the scanner has been fully connected, restore power to the terminal/computer by turning the host system power switch to the “ON” position. Power ON You must program the 3210 to work with your terminal or computer by scanning the appropriate programming bar code(s).
  • Page 15 The 3210 is ready to scan bar code for your application. Scan Bar Code Getting Started 1–6...
  • Page 16 1.5 Scanning Techniques The scanning technique for a single bar code (on a page or an object) is shown below. Single Bar Codes: BEEP! Move the 3210 Vertically The illustration below shows where to aim the red illuminated beam over the bar code for a good read. Decode Correct Incorrect...
  • Page 17 The scanning technique for multiple bar codes (on a page or object) is shown below. Multiple Bar Codes: Move the 3210 Horizontally BEEP! Note: The techniques shown are for a 3210 with automatic trigger. To scan with a manual trigger, aim the 3210 at a bar code and press the trigger (like step 2).

  • Page 18: Introduction

    QUICK START PROGRAMMING MENU 2.1 Introduction Use this chapter to program the SCANTEAM 3210 Hand Held CCD Scanner to work with your terminal/computer. About “Plug and Play” Programming With “Plug and Play” programming (Section 2.2), you connect the 3210 and scan only one bar code to program the scanner (including required prefixes/suffixes).

  • Page 19: Programming Instructions

    2.2 “Plug and Play” (Single Scan) Programming “Plug and Play” bar codes are available for the following: IBM PC Interfaces RS–232, and Wand Emulation Interfaces. Note: If your terminal or computer isn’t included in the list above, see Terminal Selection Programming – Section 2.3.
  • Page 20 Scan the appropriate “Plug and Play” single bar code. Scan Bar Code BEEP-BEEP! Note: Programming bar codes will not output data to your terminal! Quick Start Programming 2–3...
  • Page 21 After programming the 3210 for terminal interface, scan the sample bar code (below) to check that the 3210 is set up correctly for your terminal. Scan Sample Bar Code BEEP! Sample Code 39 Bar Code 12345 Note: Other Sample Bar Codes are inside the back cover of this Operating Guide and Programming Menu.
  • Page 22 IBM PC Interface Scan one of the following “Plug and Play” bar codes to program the 3210 for IBM AT, PS/2, or XT compatibles. IBM PC AT and Compatibles Interface (also PS/2 30-286, 50, 55SX, 60, 70, 70-061, 70-121, 80) IBM PS/2 and Compatibles Interface (for PS/2 25, 30 models) IBM PC XT and Compatibles Interface...
  • Page 23 RS–232 Interface Scan the following “Plug and Play” bar code to program the 3210 for RS–232. RS–232 Interface This bar code also programs the following parameters: programmable option setting Baud Rate 9600 bits per second Parity even Data Format 7 data bits, parity bit, 1 stop bit (8 Bit Data) Wand Emulation Interface Scan the following “Plug and Play”...
  • Page 24 If you’ve already programmed the 3210 using “Plug and Play” (Section 2.2), you don’t need to continue programming the 3210. 2.3 Terminal Selection Programming Use this section to program the 3210 to work with any supported terminal or computer. Programming Instructions To program the SCANTEAM 3210 using the Terminal Selection menu : Locate the two–digit terminal I.D.
  • Page 25 Scan the bar code representing the first digit of the terminal I.D. number (also on page 2–11). BEEP! Scan the bar code representing the second digit of the terminal I.D. number. BEEP- BEEP! 2–8 Quick Start Programming...
  • Page 26 The 3210 terminal interface will be set up. To program a carriage return (CR) suffix see Section 2.4. To turn off the carriage return (or any other suffix), see Section 2.5 (Clear Bar Code Suffix). Terminal Selection Programming Example You want to connect the SCANTEAM 3210 to an Esprit terminal, model 400.
  • Page 27 Supported Terminals Terminal Model(s) Terminal I.D. VT 510/520 LK411 Keyboard (DEC Style) VT 510/520 PC Style Keyboard Esprit 200, 400 HP Vectra (Mini Din) HP Vectra (Din) PC XT PS/2 25, 30 AT, PS/2 30–286, 50, 55SX, 60, 70, 70–061, 70–121, 80, 3153 Olivetti M19, M200 Olivetti...
  • Page 28 Terminal Selection Menu Scan the bar code below to program a terminal interface. Program Terminal Interface Scan the two–digit terminal I.D. number for the terminal interface you want set up ( see chart on page 2–10 ). Terminal I.D. Number Quick Start Programming 2–11...
  • Page 29 2.4 Program Carriage Return (CR) Suffix If your application requires a carrage return (CR) suffix, scan the bar code below to Program a Carriage Return for all enabled bar code symbologies. Program Carriage Return Suffix Caution: Scanning this code clears all previously programmed prefixes and suffixes.
  • Page 30 ADDITIONAL PROGRAMMING SELECTIONS If you’ve already programmed the 3210 using “Plug and Play” or Terminal Selection (Chapter 2), you don’t need to continue programming the 3210 (unless you need to set other features). 3.1 Introduction Use this chapter to program the SCANTEAM 3210 Hand Held CCD Scanner for any programmable feature.
  • Page 31 Programming Instructions Resetting Default Settings The first page of each programming section allows you to program the SCANTEAM 3210 to factory settings for that particular section. This is useful if you’ve changed the features (or don’t know what’s been programmed) and want to reset the 3210 defaults, but not all its defaults.

  • Page 32: Global Programming Bar Codes

    Global Programming Bar Codes After you’ve scanned ENTER in any programming section, you may use the bar codes below to: DEFAULT DEFAULT resets the scanner to factory settings. ESCAPE ESCAPE stops the programming sequence (programming selections are unchanged) . EXIT EXIT stops the programming sequence (any changed programming selections are saved) .

  • Page 33: Bar Code Prefix And Suffix Programming

    3.2 Bar Code Prefix and Suffix Programming Use this section to program the 3210 for Bar Code Prefix and Suffix selections. Scan the bar codes below to default the 3210 to factory settings ( ) for bar code prefix and suffix selections. ENTER Prefix/Suffix Program Mode DEFAULT All Prefix/Suffix Selections EXIT Prefix/Suffix Program Mode...

  • Page 34: Bar Code Prefix Selection

    Bar Code Prefix Selection: Code I.D. Transmit ENTER Program Mode Scan the bar code below to program Code I.D. Transmit, then choose enable or disable. Code I.D. Transmit Enable (Yes) Disable (No ) EXIT Program Mode Code I.D. Chart Symbology Code I.D.
  • Page 35 Bar Code Prefix Selection: AIM I.D. Transmit ENTER Program Mode Scan the bar code below to program AIM I.D. Transmit, then choose enable or disable. AIM I.D. Transmit Enable (Yes) Disable (No ) EXIT Program Mode AIM I.D. Chart Symbology AIM I.D.
  • Page 36 Bar Code Prefix Example To program a line feed prefix for UPC–A symbology only , scan the following bar codes: ENTER ( Prefix Selection ) Assign ASCII Character Prefix 6, 3 ( on Symbology Bar Code chart ) 0, A ( on ASCII Bar Code chart ) F, F ( on ASCII Bar Code chart ) EXIT ( Prefix Selection ) Where the:...
  • Page 37 Bar Code Prefix Selection: Assign ASCII Character Prefix ENTER Program Mode Scan the bar code below to start assigning an ASCII character prefix. Assign ASCII Character Prefix Refer to the chart below, then scan the two bar codes on the next page that represent the bar code symbology requiring a prefix.
  • Page 38 Symbology Bar Codes Additional Programming 3–9...
  • Page 39 Bar Code Prefix Selection: Assign ASCII Character Prefix, continued Refer to the chart below to find the hex value of the prefix you wish to assign. Hex – ASCII Chart " & < > Scan two of the ASCII Bar Codes (next page) that represent the hex digits of the prefix you require.
  • Page 40 ASCII Bar Codes Additional Programming 3–11...

  • Page 41: Bar Code Suffix Selection

    Bar Code Suffix Selection: Assign ASCII Character Suffix ENTER Program Mode Scan the bar code below to start assigning an ASCII character suffix. Assign ASCII Character Suffix Refer to the chart below, then scan the two bar codes on the next page that represent the bar code symbology requiring a suffix.
  • Page 42 Symbology Bar Codes Additional Programming 3–13...
  • Page 43 Bar Code Suffix Selection: Assign ASCII Character Suffix, continued Refer to the chart below to find the hex value of the suffix you wish to assign. Hex – ASCII Chart " & < > Scan two of the ASCII Bar Codes (next page) that represent the hex digits of the suffix you require.
  • Page 44 ASCII Bar Codes Additional Programming 3–15...

  • Page 45: Output Programming

    3.3 Output Programming Use this section to program the 3210 for Output selections. Scan the bar codes below to default the 3210 to factory settings ( ) for output selections. ENTER Output Program Mode DEFAULT All Output Selections EXIT Output Program Mode 3–16 Additional Programming...

  • Page 46: Beeper Selection

    Beeper Selection ENTER Program Mode Scan the bar code below to program Beeper selection, then choose the volume you want. Beeper Selection Beeper Off Beeper Low Volume Beeper Medium Volume Beeper High Volume EXIT Program Mode Additional Programming 3–17...

  • Page 47: Keyboard Style Selection

    Keyboard Style Selection ENTER Program Mode Scan the bar code below to program Keyboard Style selection, then choose the keyboard style you want. Keyboard Style Selection Style A Style B Style C Style D Style F Style G 3–18 Additional Programming...
  • Page 48 Keyboard Style Selection, continued Style H Style I Style J EXIT Program Mode The charts on the following pages show the keyboard style for supported terminals. Note: Styles A, B, and C cannot be used with one another; however they be combined with other styles.
  • Page 49 Terminal Keyboard Style Name Primary Secondary Tertiary Quaternary DirCon AutoCaps NumPad Turbo Auto DC IBM XT CAPS SHFT CTRL LOCK LOCK ASCII IBM PS/2 CAPS SHFT CTRL 12/9 LOCK LOCK ASCII IBM AT CAPS SHFT CTRL 14/3 LOCK LOCK ASCII IBM AT3 CAPS SHFT CTRL...

  • Page 50: Keyboard Emulation Mode

    The Keyboard Style Table below applies to Note: SCANTEAM 3210 software prior to software revision level 2.0. Keyboard Style (If terminal is not listed, then no secondary type keyboard is supported.) Terminal Primary Secondary Tertiary Quaternary Quinquenary IBM PC/XT CAPS LOCK SHIFT LOCK CTRL "...

  • Page 51: Intercharacter Delay Selection

    Programmable Output Delay Selections ENTER Program Mode Scan the bar code below to start Intercharacter Delay selection. Intercharacter Delay Selection Scan two of the Numeric Bar Codes (next page) to set the delay to any value between 00 and 99 (multiples of 5ms). Scan the bar code below to start Interfunction Delay selection.
  • Page 52 Numeric Bar Codes Programmable Output Delay Example The SCANTEAM 3210 is programmed as follows: Intercharacter Delay = 10ms Interfunction Delay = 50ms Bar Code Suffix = Tab and Carriage Return When a bar code symbol containing the characters “123” is scanned, the 3210 will output the following to the terminal / computer: Carriage Return 10ms...

  • Page 53: Output Mode Selection

    Output Mode Selection: Buffer Scans ENTER Program Mode Scan the bar code below to start Output Mode selection. Output Mode Selection Scan the bar code below to program Buffer Scans, then choose enable or disable. If enabled , the 3210 accepts a second scan while transmitting the current scan to the terminal.

  • Page 54: Function Code Transmit

    Output Mode Selection: Function Code Transmit ENTER Program Mode Scan the bar code below to start Output Mode selection. Output Mode Selection Scan the bar code below to program Function Code Transmit, then choose enable or disable. Refer to Chapter 4 for Function Code tables (Supported Interface Keys).
  • Page 55 Output Mode Selection, continued Function Code Transmit Enabled Example The SCANTEAM 3210 is connected to an IBM PC XT and is programmed as follows: Bar Code Prefix: GS (1D)==>F10 key Bar Code Suffix: CR (0D)==>ENTER key Function Code Transmit, enabled When a bar code containing the characters “1234<HT>5678”...

  • Page 56: Laser Redundancy

    Output Mode Selection: Laser Redundancy ENTER Program Mode Scan the bar code below to start Output Mode selection. Output Mode Selection Scan the bar code below to program Laser Redundancy, then choose enable or disable. If enabled , the 3210 requires three identical scans before data will be accepted.

  • Page 57: Country Code Selection

    Country Code Selection ENTER Program Mode Scan the bar code below to start Country Code selection. Country Code Selection Refer to the chart below to find the numeric value of the country keyboard you require. Country Code United States Belgium Denmark Finland Norway...
  • Page 58 Numeric Bar Codes Additional Programming 3–29...

  • Page 59: Industrial Symbology Programming

    3.4 Industrial Symbology Programming Use this section to program the 3210 for Industrial Symbology selections. Scan the bar codes below to default the 3210 to factory settings ( ) for industrial symbology selections. ENTER Industrial Symbology Program Mode DEFAULT All Industrial Symbology Selections EXIT Industrial Symbology Program Mode Examples of Industrial bar codes may be found on page 3–34 in this programming section.

  • Page 60: Codabar Selection

    Codabar Selection ENTER Program Mode Scan the bar code below to start Codabar symbology selection, then enable or disable Codabar decoding. Codabar Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes. To set minimum allowable length, scan the “Set Minimum Length”...
  • Page 61 Codabar Selection, continued Scan the bar code below to program Codabar Start/Stop Transmit, then choose enable or disable. Start/Stop Transmit Enable (Yes) Disable (No ) Scan the bar code below to program Codabar Check Character Required, then choose enable or disable. Check Character Required Enable (Yes) Disable (No )
  • Page 62 Codabar Selection, continued Scan the bar code below to program Codabar Concatenation, then choose enable or disable. Concatenation Enable (Yes ) Disable (No) Scan the bar code below to program Codabar Concatenation Required, then choose enable or disable. Concatenation Required Enable (Yes) Disable (No ) EXIT Program Mode...
  • Page 63 B+12345–C Start Character Stop Character Codabar without Concantenation A12D D34A Concantenation Start Character Stop Character Scan would look like: A1234A Codabar with Concantenation Codabar Bar Code *TEST–SHEET* Start Character Stop Character Code 39 Bar Code 3–34 Additional Programming...

  • Page 64: Code 39 Selection

    Code 39 Selection ENTER Program Mode Scan the bar code below to start Code 39 symbology selection, then enable or disable Code 39 decoding. Code 39 Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes.
  • Page 65 Code 39 Selection, continued Scan the bar code below to program Code 39 Start/Stop Transmit, then choose enable or disable. Start/Stop Transmit Enable (Yes) Disable (No ) Scan the bar code below to program Code 39 Check Character Required, then choose enable or disable. Check Character Required Enable (Yes) Disable (No )
  • Page 66 Code 39 Selection, continued Scan the bar code below to program Code 39 Full ASCII, then choose enable or disable. Full ASCII Enable (Yes ) Disable (No) Scan the bar code below to program Code 39 Append Option, then choose enable or disable. Append Option Enable (Yes) Disable (No )

  • Page 67: Interleaved 2 Of 5 Selection

    Interleaved 2 of 5 Selection ENTER Program Mode Scan the bar code below to start Interleaved 2 of 5 symbology selection, then enable or disable Interleaved 2 of 5 decoding. Interleaved 2 of 5 Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes.
  • Page 68 Interleaved 2 of 5 Selection, continued Scan the bar code below to program Interleaved 2 of 5 Check Digit Required, then choose enable or disable. Check Digit Required Enable (Yes) Disable (No ) Scan the bar code below to program Interleaved 2 of 5 Check Digit Transmit, then choose enable or disable.

  • Page 69: Code 2 Of 5 Selection

    Code 2 of 5 Selection ENTER Program Mode Scan the bar code below to start Code 2 of 5 symbology selection, then enable or disable Code 2 of 5 decoding. Code 2 of 5 Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes.

  • Page 70: Matrix 2 Of 5 Selection

    Matrix 2 of 5 Selection ENTER Program Mode Scan the bar code below to start Matrix 2 of 5 symbology selection, then enable or disable Matrix 2 of 5 decoding. Matrix 2 of 5 Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes.

  • Page 71: Code 11 Selection

    Code 11 Selection ENTER Program Mode Scan the bar code below to start Code 11 symbology selection, then enable or disable Code 11 decoding. Code 11 Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes.
  • Page 72 Code 11 Selection, continued Scan the bar code below to program Code 11 2 Check Digits Required?, then choose enable or disable. 2 Check Digits Required? Enable (Yes ) Disable (No [) [ No (Disabled) = 1 Check Digit EXIT Program Mode Additional Programming 3–43...

  • Page 73: Code 93 Selection

    Code 93 Selection ENTER Program Mode Scan the bar code below to start Code 93 symbology selection, then enable or disable Code 93 decoding. Code 93 Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes.

  • Page 74: Code 128 Selection

    Code 128 Selection ENTER Program Mode Scan the bar code below to start Code 128 symbology selection, then enable or disable Code 128 decoding. Code 128 Selection Enable (Yes ) Disable (No) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes.

  • Page 75: Disable All Symbologies

    Code 128 Selection, continued EAN–128 Programming When enabled, the 3400 substitutes a <GS> for Function Character 1. <GS> Substitution Enable (Yes ) Disable (No) Note: For complete EAN-128 support, the AIM code ID feature also should be enabled. Refer to Page 3–6. EXIT Program Mode Disable All Symbologies ENTER Program Mode...
  • Page 76 Industrial Symbologies Min/Max Length Chart Symbology Minimum Length Maximum Length Codabar Code 39 Interleaved 2 of 5 02 [ Code 2 of 5 01 [ Matrix 2 of 5 01 [ Code 11 01 [ Code 93 Code 128 [ The Default minimum length for these symbologies is 4 characters. Numeric Bar Codes Additional Programming 3–47...

  • Page 77: Retail Symbology Programming

    3.5 Retail Symbology Programming Use this section to program the 3210 for Retail Symbology selections. Scan the bar codes below to default the 3210 to factory settings ( ) for retail symbology selections. ENTER Retail Symbology Program Mode DEFAULT All Retail Symbology Selections EXIT Retail Symbology Program Mode Examples of Retail bar codes may be found on pages 3–52, 3–56, and 3–57 in this programming section.

  • Page 78: Upc Selection

    UPC Selection ENTER Program Mode Scan the bar code below to start UPC symbology selection. UPC Selection UPC selections include: Version A, Version E0, Version E1, Check Digit Transmit, Number System Transmit, Version E Expand, 2–Digit Addendum, and 5–Digit Addendum. Scan the bar code below to program UPC Version A, then choose enable or disable.
  • Page 79 UPC Selection, continued Scan the bar code below to program UPC Version E1, then choose enable or disable. Version E1 Enable (Yes) Disable (No ) Scan the bar code below to program UPC Check Digit Transmit, then choose enable or disable. Check Digit Transmit Enable (Yes ) Disable (No)
  • Page 80 UPC Selection, continued Scan the bar code below to program UPC Version E Expand, then choose enable or disable. Version E Expand Enable (Yes) Disable (No ) Scan the bar code below to program UPC 2–Digit Addenda, then choose enable or disable. 2–Digit Addenda Enable (Yes) Disable (No )
  • Page 81 UPC Selection, continued EXIT Program Mode 12345 0 31425 60789 5 # System Check Digit 5–Digit Addendum UPC–A Bar Code 0 12345 00350 9 # System Check Digit NO Addendum UPC–A Bar Code 3–52 Additional Programming...

  • Page 82: Ean Selection

    EAN Selection ENTER Program Mode Scan the bar code below to start EAN symbology selection. EAN Selection EAN selections include: EAN/JAN 13, EAN/JAN 8, Check Digit Transmit, 2–Digit Addendum, 5–Digit Addendum, and ISBN Enable. Scan the bar code below to program EAN/JAN 13, then choose enable or disable.
  • Page 83 EAN Selection, continued Scan the bar code below to program EAN/JAN 8, then choose enable or disable. EAN/JAN 8 Enable (Yes ) Disable (No) Scan the bar code below to program EAN Check Digit Transmit, then choose enable or disable. Check Digit Transmit Enable (Yes ) Disable (No)
  • Page 84 EAN Selection, continued Scan the bar code below to program EAN 5–Digit Addenda, then choose enable or disable. 5–Digit Addenda Enable (Yes) Disable (No ) Scan the bar code below to program EAN ISBN Enable, then choose enable or disable. ISBN Enable Enable (Yes) Disable (No )
  • Page 85 50595 97 80123 8 8 Digits Check Digit 5–Digit Addendum EAN 8 Bar Code 97 80123 8 8 Digits Check Digit NO Addendum EAN 8 Bar Code 3–56 Additional Programming...
  • Page 86 50595 9 780123 456793 13 Digits Check Digit 5–Digit Addendum EAN 13 Bar Code 9 781853 360824 13 Digits Check Digit NO Addendum EAN 13 Bar Code Additional Programming 3–57...

  • Page 87: Upc & Ean Addenda Selection

    UPC & EAN Addenda Selection ENTER Program Mode Scan the bar code below to program UPC & EAN Addenda Required, then choose enable or disable. UPC & EAN Addenda Required Enable (Yes) Disable (No ) Scan the bar code below to program UPC/EAN Format, then choose to add a space or not to add a space between the UPC/EAN code and addenda.

  • Page 88: Msi Selection

    MSI Selection ENTER Program Mode Scan the bar code below to start MSI symbology selection, then enable or disable MSI decoding. MSI Selection Enable (Yes) Disable (No ) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes. To set minimum allowable length, scan the “Set Minimum Length”...

  • Page 89: Plessey Selection

    Plessey Selection ENTER Program Mode Scan the bar code below to start Plessey symbology selection, then enable or disable Plessey decoding. Plessey Selection Enable (Yes) Disable (No ) Note: If you don’t need to program additional selections, you may scan EXIT now to exit program mode and save your changes. To set minimum allowable length, scan the “Set Minimum Length”...

  • Page 90: Disable All Symbologies

    Disable All Symbologies ENTER Program Mode Scan the bar code below to Disable ALL Symbologies. Caution: You will not be prompted to verify this option. Disable All Symbologies EXIT Program Mode Note: All Industrial Symbologies will be disabled also. Additional Programming 3–61...
  • Page 91 Retail Symbologies Min/Max Length Chart Symbology Minimum Length Maximum Length Plessey Numeric Bar Codes 3–62 Additional Programming...

  • Page 92: Programming

    3.6 RS–232 Programming Use this section to program the 3210 for RS–232 selections. Scan the bar codes below to default the 3210 to factory settings ( ) for RS–232 selections. ENTER RS–232 Program Mode DEFAULT All RS–232 Selections EXIT RS–232 Program Mode Additional Programming 3–63...

  • Page 93: Baud Rate Selection

    Baud Rate Selection ENTER Program Mode Scan the bar code below to program Baud Rate selection, then choose the baud rate you want. Baud Rate Selection 300 bps (bits per second) 4800 bps (bits per second) 600 bps (bits per second) 9600 bps (bits per second) 1200 bps (bits per second) 19200 bps (bits per second)

  • Page 94: Parity Selection

    Parity Selection ENTER Program Mode Scan the bar code below to program Parity selection, then choose the parity you want. Parity Selection None Mark Space Even EXIT Program Mode Additional Programming 3–65...

  • Page 95: Data Format Selection

    Data Format Selection ENTER Program Mode Scan the bar code below to program Data Format selection, then choose the data format you want. Data Format Selection 7 Data, Parity, 1 Stop 7 Data, Parity, 2 Stop 8 Data, Parity, 1 Stop EXIT Program Mode 3–66 Additional Programming...

  • Page 96: Cts Handshake Selection

    CTS Handshake Selection ENTER Program Mode This selection allows you to disable the CTS Handshake if your terminal/computer doesn’t have a CTS I/O line. Scan the bar code below to program CTS Handshake selection, then choose enable or disable. CTS Handshake Selection Enable (Yes) Disable (No ) CTS Handshake only applies when the 3210 is in Serial Mode (RS–232,...

  • Page 97: Data Formatter (Bar Code Editor) Programming

    3.7 Data Formatter (Bar Code Editor) Programming Use this section to program the 3210 for Data Formatter (Bar Code Editor) selections. Scan the bar codes below to default the 3210 to factory settings ( ) for Data Formatter selections. ENTER Data Formatter Program Mode DEFAULT All Data Formatter Selections EXIT Data Formatter Program Mode 3–68...

  • Page 98: Require Data Format

    Require Data Format ENTER Program Mode Scan the bar code below to program Require Data Format, then choose enable or disable. Require Data Format Enable (Yes) Disable (No ) EXIT Program Mode Additional Programming 3–69...

  • Page 99: Format Editor Selection

    Format Editor Selection ENTER Program Mode To make Data Format Editor selections, you’ll need to know the terminal type, code I.D., code length, and editor commands your application requires. Use the Alpha–numeric bar codes (next page) to scan these options. Scan the bar code below to start Format Editor selection.
  • Page 100 Alpha-numeric Bar Codes (for Format Editor Selection) Additional Programming 3–71...
  • Page 101 Format Editor Commands Chart Send Commands F1 Send all characters followed by XX" key or function code, starting from current cursor position. Syntax = F1XX (XX = HEX ASCII character or function code 00-FE HEX). F2 Send NN" characters followed by XX" key or function code, starting from current cursor position.

  • Page 102: Delete All Formats

    Delete All Formats ENTER Program Mode Scan the bar code below to Delete ALL Formats, then scan “Yes” if you are sure you want to delete all formats or “No” if you do not want to delete all formats. Delete All Formats EXIT Program Mode Additional Programming 3–73...

  • Page 103: Trigger And Reread Delay Programming

    3.8 Trigger and Reread Delay Programming Use this section to program the 3210 for Trigger/Reread Delay selections. Scan the bar codes below to default the 3210 to factory settings ( ) for Trigger/Reread Delay selections. ENTER Trigger/Reread Delay Program Mode DEFAULT All Trigger/Reread Delay Selections EXIT Trigger/Reread Delay Program Mode 3–74...

  • Page 104: Trigger Mode Selection

    Trigger Mode Selection ENTER Program Mode Scan the bar code below to program Trigger Mode selection, then choose the trigger option you want. Trigger Mode Selection Auto–Trigger Manual Trigger Manual Trigger – Switched Power Trigger Mode only available with RS–232 and Wand Emulation Interface configurations.

  • Page 105: Reread Delay Selection

    Reread Delay Selection ENTER Program Mode Scan the bar code below to program Reread Delay selection, then choose the delay you want. Reread Delay Selection Low (175 milliseconds) Medium (450 milliseconds) High (1.0 second) Extra High (2.0 seconds) EXIT Program Mode 3–76 Additional Programming...

  • Page 106: Good Read Delay Selection

    Good Read Delay Selection ENTER Program Mode Scan the bar code below to program Good Read Delay selection, then choose the delay you want. Good Read Delay Selection None Low (500 milliseconds) Medium (1.0 second) High (1.5 seconds) EXIT Program Mode Additional Programming 3–77...

  • Page 107: Wand Emulation Programming

    3.9 Wand Emulation Programming Use this section to program the 3210 for Wand Emulation selections. Scan the bar codes below to default the 3210 to factory settings ( ) for wand emulation selections. ENTER Wand Emulation Program Mode DEFAULT All Wand Emulation Selections EXIT Wand Emulation Program Mode 3–78 Additional Programming...

  • Page 108: Output Polarity Selection

    Output Polarity Selection ENTER Program Mode Scan the bar code below to program Output Polarity selection, then choose the polarity you want. Output Polarity Selection (Wand Emulation) White High Black High EXIT Program Mode Additional Programming 3–79...

  • Page 109: Transmission Rate Selection

    Transmission Rate Selection ENTER Program Mode Scan the bar code below to program Transmission Rate selection, then choose the transmission rate you want. Transmission Rate Selection 10 ips (inches per second) 120 ips (inches per second) 25 ips (inches per second) 150 ips (inches per second) 40 ips (inches per second) 200 ips (inches per second)

  • Page 110: Status Check

    3.10 Status Check Use this section to request a 3210 Status Check. Scan the ENTER bar code to start Status Check. ENTER Status Check Mode Scan the bar code below to show formats status. One format per line will be printed out. Show Formats ENTER Status Check Mode Scan the bar code to show the software revision level.
  • Page 111 3–82 Additional Programming...

  • Page 112: Chapter 4 Supported Interface Keys

    SUPPORTED INTERFACE KEYS 4.1 Keyboard Function Relationships The following Keyboard Function Code, HEX/ASCII Value, and Full ASCII “CTRL”+ relationships apply to all terminals that can be used with the SCANTEAM 3210 Hand Held CCD scanner. Function Code HEX/ASCII Value Full ASCII “CTRL” + Interface Keys 4–1...
  • Page 113 The last five characters in the Full ASCII “CTRL”+ column ( [ \ ] 6 - ) apply to US only. The following chart indicates the equivalents of these five characters for different countries. Country Codes United States Belgium < Scandinavia <...
  • Page 114 4.2 Supported Interface Keys IBM AT and PS/2 Compatibles Supported Key Function Interface Keys RESERVED ENTER (KP) CAP LOCK RESERVED RESERVED RESERVED RESERVED CR/ENTER RESERVED RESERVED DELETE CR/ENTER INSERT ESCAPE HOME PRINT BACKSPACE BACK TAB Interface Keys 4–3...
  • Page 115 Supported Interface Keys IBM XTs and Compatibles Supported Key Function Interface Keys RESERVED CR/ENTER CAPS LOCK RESERVED RESERVED RESERVED RESERVED CR/ENTER RESERVED RESERVED DELETE CR/ENTER INSERT RESERVED RESERVED HOME PRINT BACKSPACE BACK TAB RESERVED Interface Keys 4–4...
  • Page 116 FULL ASCII CODE 39 BAR CODE CHART %U (NUL) $H (BS) $A (SOH) $I (HT) $B (STX) $J (LF) $C (ETX) $K (VT) $D (EOT) $L (FF) $E (ENQ) $M (CR) $F (ACK) $N (SO) $G (BEL) $O (SI) Code 39 Chart 4–5...
  • Page 117 $P (DLE) $X (CAN) $Q (DC1) $Y (EM) $R (DC2) $Z (SUB) $S (DC3) %A (ESC) $T (DC4) %B (FS) $U (NAK) %C (GS) $V (SYN) %D (RS) $W (ETB) %E (US) 4–6 Code 39 Chart...

  • Page 118: Chapter 5 Product Specifications And Pinouts

    PRODUCT SPECIFICATIONS AND PINOUTS 5.1 Environmental Specifications parameter specification Operating Temperature 32 F to 122 F [0 C to 50 C] Storage Temperature –40 F to 158 F [–40 C to 70 C] Humidity 0% to 95% RH noncondensing Barometric Pressure 101,000 to 69,000 Pascals [Sea level to 3,000 meters] Mechanical Shock...

  • Page 119: Scanner Performance

    5.3 Scanner Performance parameter specification Pitch Angle 7 degrees Skew Angle 30 degrees Minimum Reflective Difference 37.5% (MRD) Scan Rate 50 scans per second Field Width 2.2 inches [55mm] at contact Illumination 660 nm Visible Red Light Emitting Diodes (LED) with focusing reflector Working Distance Near contact Resolution...

  • Page 120: Pinouts

    5.4 Pinouts AT/XT/PS2 Keyboard Wedge Decoded output data format provided at 8 pin RJ41 modular connector (in scanner handle). See chart below. 8 Pin RJ41 Modular Connector Standard Welch Allyn Signal Function Color Code Braid Cord Shield Blue Prog 1...
  • Page 121 Pinouts, continued RS–232 Decoded output data format provided at 8 pin RJ41 modular connector (in scanner handle). See chart below. 8 Pin RJ41 Modular Connector Standard Welch Allyn Signal Function Color Code Braid Cord Shield Blue Prog 1 Black Ground...

  • Page 122: Wand Emulation

    Pinouts, continued Wand Emulation Conventional wand data format provided at 8 pin RJ41 modular connector (in scanner handle). See chart below. 8 Pin RJ41 Modular Connector Standard Welch Allyn Signal Function Color Code Braid Cord Shield Blue +5VDC 5 Volt Power Connection...

  • Page 123: General Dimensions

    5.5 General Dimensions SCANTEAM 3210 Side View Belt Loop (for portable applications) 3/4 View 5.84 in [14.8cm] 5.83 in [14.8cm] Front View 2.97 in Top View [7.5cm] 5–6 Specifications and Pinouts...

  • Page 124: Chapter 6 Maintenance And Troubleshooting Guide

    Inspect the 3210’s interface cable and connector for wear or other signs of damage. A badly worn cable or damaged connector may interfere with scanner operation. Contact your Welch Allyn distributor for information about scanner repair. Maintenance and Troubleshooting 6–1...

  • Page 125: Replacing The Interface Cable

    The cable’s designed to be field replaceable. Notes: Order replacement cables from Welch Allyn or from an authorized distributor. When ordering a replacement cable, specify the cable part number of the original interface cable.

  • Page 126: Troubleshooting

    6.2 Troubleshooting The SCANTEAM 3210 automatically performs self–tests whenever you turn it on. If your scanner is not functioning properly, review the following Troubleshooting Guide to try to isolate the problem. Troubleshooting Guide Is the power on? Is the red illuminated beam on? If the red scan beam on the 3210 isn’t illuminated, check that: the cable is connected properly .
  • Page 127 Does the 3210 read your bar code incorrectly? If the 3210 reads a bar code ( one beep for a good read ), but the bar code is not displayed correctly on the host screen: The 3210 may not be programmed for the appropriate terminal interface.
  • Page 128 Section 2.4 and scan the “Factory Default Settings” bar code. If All Else Fails... If you are still experiencing problems, call your Distributor or Welch Allyn: 315–685–8945 (8 a.m. to 4:30 p.m. EST) (For more information on Customer Support or Warranty information see the two sections following this chapter.)
  • Page 129 Maintenance and Troubleshooting 6–6...

  • Page 130: Customer Support

    Skaneateles, New York. To obtain warranty or non–warranty service, return the unit to Welch Allyn (postage paid) with a copy of the dated purchase record attached. In the United States, please contact the Welch Allyn Product...
  • Page 131 Buckinghamshire HP22 4ND England Telephone: Int+44 1296 682140 Fax: Int+44 1296 682104 For service in Asia, please contact your Welch Allyn representative (at address below) or your local distributor. Welch Allyn, Hong Kong Office 10/F Tung Sun Commercial Centre 194–200 Lockhart Road Wanchai, Hong Kong Telephone: Int+852–2511–3050 or 2511–3132...

  • Page 132: Limited Warranty

    SCANTEAM 3210 that fails to perform according to its published specifications during a period of three (3) years from the time of shipment by Welch Allyn (or from a Welch Allyn authorized distributor) to the user. Any attempt on the part of the user to disassemble or service the scanner will void the warranty.
  • Page 133 RESULTING FROM THE BREACH OF ANY EXPRESS WARRANTY EXCEPT AS SET FORTH HEREIN. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. This warranty gives you specific legal rights and you may also have other rights which vary from state to state or country to country.

  • Page 134: Hex Ascii (Conversion) Chart

    HEX ASCII (CONVERSION) CHART BIT NUMBERS COLUMN ‘ ” & ’ < – > CONTROL FUNCTION DEFINITIONS Null, or all zeros Vertical tabulation Synchronous idle Start of heading Form feed End of transmission block Start of text Carriage Return Cancel End of text Shift out End of medium...
  • Page 135 6–12 Hex ASCII Chart...

  • Page 136: Index

    INDEX Assign ASCII Character Prefix, 3-8 Code I.D. Transmit, 3-5 Additional Programming Options, Suffix Selection, Assign ASCII Character Suffix, 3-12 Alpha-Numeric Bar Codes, Barometric Pressure, 5-1 3-71 Belt Loop. See General Ambient Illumination, 5-1 Dimensions ASCII Bar Codes, 3-11, 3-15 ASCII Conversion Chart, 6-11 Control Function Definitions, 6-11...
  • Page 137 Code 39, Full ASCII Chart, 4-5 ESD Protection, 5-1 Humidity, 5-1 Code Density, 5-2 Pressure, 5-1 Connecting the Scanner, 1-4 Shock, 5-1 Temperature, 5-1 Connector Pinouts. See Pinouts Escape Bar Code, 3-3 Country Code Chart, 3-28 ESD Sensitivity, 5-1 Current Draw, 5-1 Exit Bar Code, 3-3 Customer Support, 6-5, 6-7 Factory Defaults.
  • Page 138 In-Rush Current, 5-1 Interface Cable Replacement. See Replacing the Interface Cable Industrial Symbologies Min/Max Length Chart, 3-47 Industrial Symbology Programming, 3-30 3-47 Codabar Selection, 3-31 Keyboard Function Codes, 4-1 Check Character Required, Keyboard Function Relationships, 3-32 Check Character Transmit, 3-32 Keyboard Style Chart, 3-20, Concatenation, 3-33 3-21...
  • Page 139 Trigger Option, 1-3 Output Mode Selection Buffer Scans, 3-24 Model Number. See Identification Function Code Transmit, Label 3-25 MRD. See Scanner Performance Laser Redundancy, 3-27 MTBF. See Electrical Specifications Pinouts, 5-3 Keyboard Wedge, 5-3 RS-232, 5-4 Noise Rejection. See Electrical Wand Emulation, 5-5 Specifications Pitch Angle, 5-2...
  • Page 140 Data Formatter (Bar Code Programming Status. See Status Editor), 3-68 3-73 Check IBM PC Interfaces, 2-5 Industrial Symbology, 3-30 3-47 Output Parameters, 3-16 3-29 Repairs Retail Symbology, 3-48 3-62 Non-warranty, 6-7 RS-232, 3-63 3-67 Warranty, 6-7 RS-232 Interface, 2-6 Replacing the Interface Cable, Trigger/Reread Delay, 3-74 3-77 Reset Factory Settings, 2-1,...
  • Page 141 Version E Expand, 3-51 Instant Interface, 1-1 Model Identification, 1-3 Version E0, 3-49 Scanner Connection, 1-4 Version E1, 3-50 Scanner Identification, 1-3 RS-232 Programming, Scanning Techniques, 1-7 3-63 3-67 Unpacking, 1-2 Beeper Selection, 3-64 Serial Number. See Identification CTS Handshake Selection, Label 3-67 Data Format Selection, 3-66...
  • Page 142 Troubleshooting, 6-3 Welch Allyn Offices Hong Kong, 6-8 Troubleshooting Guide, 6-3 6-5 Ireland, 6-7 United States, 6-7 Welch Allyn Product Service Unpacking the 3210, 1-2 Asia, 6-8 Upgrading 3210 Software, 1-1 Europe and Great Britain, 6-7 United States, 6-7 Width. See General Dimensions...
  • Page 143 Index viii...
  • Page 144 SAMPLE BAR CODES Codabar Code 39 0013557900 TEST–SHEET Interleaved 2 of 5 Code 2 of 5 1234567890 Matrix 2 of 5 123456 Code 11 6543210 Code 128 11223344 CODE 128 UPC-A 5 addenda 031323120786 56098 EAN 13 MSI [ 9780330290951 Plessey [ 44332211 [ Programming the DEFAULT All Retail...
  • Page 145 Data Collection Division 4619 Jordan Road P.O. Box 187 3210/DO/UG Rev D Skaneateles Falls, New York 13153–0187...

This manual is also suitable for:

Scanteam 3210/d seriesScanteam 3210/d-13

Table of Contents
