Operating Instructions
CLV490 Bar Code Scanner
5

Electrical installation

CLV490 Type Temperature
range
0 to +40 °C
CLV490 without
(+32 to +104 °F)

heater

CLV490 with heater –35 to +35 °C
(–31 to +95 °F)

Table 5-1: Connection Modules for the CLV490

8009993/RA61/2007-07-20
Electrical installation
5.1

Installation sequence

•
Connect the CLV490 to a CDB420 or CDM490 Connection Module, or using a custom-
er-specific wiring configuration
•
Connect the data and function interfaces of the CLV490 in the module
•
Connect the PC to the Connection Module (at the auxiliary interface on the CLV490)
•
Connect the power supply to the Connection Module
5.1.1

SICK Connection Modules (overview)

Connection Purpose
module
CDB420-001 – Connecting one CLV490
CDB420-101
– 1 x 15-pin D Sub HD socket, 4 x cable gland
– Operating voltage 18 to 30 V DC
– Enclosure rating max. IP 65
CDM490-0001 – Connecting one CLV490
– 1 x 15-pin D Sub HD plug, 1 x socket,
– Operating voltage 18 to 30 V DC
– Enclosure rating max. IP 65
CDM490-0001 – Connecting one CLV490
– 1 x 15-pin D Sub HD plug, 1 x socket,
– Operating voltage 24 V DC +20 %/–10 %
– Enclosure rating max. IP 65 (with connector cover)
For technical data on the modules see
5.2

Electrical connections and cables

The electrical connections on the CLV490 consist of two 15-pin D Sub HD connections on
the housing, one plug, and one socket.
These connections are used to route the following interfaces:
•
Three data serial interfaces (host interface, CAN interface 1 and 2, auxiliary interface)
•
Six switching inputs (external reading pulse and multifunctional inputs)
•
Four switching outputs (for result status function, for connecting to a PLC for example)
•

Power supply

5.2.1

Wire cross-sections

CLV490 without heater:
All connections must be wired with copper cables with a minimum wire diameter of
0.15 mm (approx. 26 AWG)!
2
© SICK AG · Division Auto Ident · Germany · All rights reserved
(CDB420-101: 2 x cable gland, 2 x M12 plug
connection (1 x plug, 1 x socket))
6 x cable gland
6 x cable gland
Chapter 10.13.3 Accessories: Hoods, Page
Chapter 5
see
chapter
5.2.3
5.2.4
5.2.4
10-75.
5-1
