VAA-2E-G4-SN
Assignment of the connections
The following function devices can be used in this application while
operating the AS-Interface safety slave together with a safety monitor of
types VAS-1A-K12-U or VAS-2A-K12-U to meet the requirements of
Category 4:
Warning
Attention
22
Subject to reasonable modifications due to technical advances.
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Two-channel positively driven
Two-channel dependent
The function device "
not
be used.
The cable length between the VAA-2E-G4-SN and the
sensor is limited to 30 m for both the position switch and the
proximity switch.
two-channel independent" must
