Connections, displays and control elements

Connections
The sensor connections consist of cage clamp terminals.
Either one mechanical position switch or a SN/S1N proximity switch may
be connected to each channel.
Connections
1.1
1.2
1.3
2.1
2.2
2.3
3.1
3.2
3.3
4.1
4.2
4.3
Note
Subject to reasonable modifications due to technical advances.
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Connections, displays and control elements
Mechanical position switch 1 +
Reserved
Mechanical position switch 1 +
Mechanical position switch 2 +
Reserved
Mechanical position switch 2 +
SN/S1N proximity switch 1 +
Proximity switch 1 emulation
SN/S1N proximity switch 1 -
SN/S1N proximity switch 2 -
Proximity switch 2 emulation
SN/S1N proximity switch 2 +
Terminals 1.2 and 2.2 are reserved and must not be
assigned (used).
Each of the unassigned terminals should be wired as
follows:
VAA-2E-G4-SN
S+1
RES
S-1
S-2
RES
S+2
S+1
EM1
L-1
L-2
EM2
L+2
