- Page 1 FACTORY AUTOMATION MANUAL AFETY UTPUT ODULE WITH IAGNOSTIC LAVE...
- Page 2 AS-i Safety Output Module with Diagnostic Slave With regard to the supply of products, the current issue of the following document is applicable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
-
Page 3: Table Of Contents
AS-i Safety Output Module with Diagnostic Slave Table of contents Introduction...................4 Declaration of conformity ..............5 Declaration of conformity................5 Safety .....................6 Experienced staff ..................... 6 Application area of the device ................ 6 Correct use ....................... 7 Disposal ......................7 General Remarks ..................8 Product information .................. -
Page 4: Introduction
Introduction Introduction Congratulations You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs de- velops, produces and distributes electronic sensors and interface modules for the market of automation technology on a worldwide scale. Before installing this equipment and put into operation, read this manual carefully. -
Page 5: Declaration Of Conformity
This product was developed and manufactured under observance of the applica- ble European standards and guidelines. Information! A Declaration of Conformity can be requested from the manufacturer. The product manufacturer, Pepperl+Fuchs GmbH, D-68307 Mannheim, has a certified quality assurance system that conforms to ISO 9001. -
Page 6: Safety
VBA-4E2A1A-KE3-ZEL/E2L/SEL . A special characteristic of this module is its three different kinds of AS-i address- • safety output VBA-4E2A1A-KE3-ZEL/E2L/SEL listens to the communication on the safe address and switches based on these data. • 4I input slave One standard AS-i slave (AB slave) for polling inputs I1, I2, I3 and 1.Y1... -
Page 7: Correct Use
Information! If used in a way differing from this description or if the device has been changed in any way – even during installation – any warranty claims with respect to Pepperl+Fuchs GmbH are invalid. Disposal Information! Electronic waste is hazardous waste. -
Page 8: General Remarks
Please read this chapter carefully before working with the documentation and the "AS-i Safety Output Module with Diagnostic Slave". Product information This user manual is valid for the following Pepperl+Fuchs GmbH devices AS-i Safety Output Module with Diagnostic VBA-4E2A1A-KE3-ZEL/E2L/ Slave 1 EDM input, 3I and 2O... -
Page 9: Product Description
AS-i Safety Output Module with Diagnostic Slave Product Description Product Description This chapter is intended to inform the reader about the special characteristics of the AS-i Safety Output Module with Diagnostic Slave. It describes the design and the functionality of the devices. Warning! This chapter must be read before installation and operation of the device in conjunction with other safety components on protected machinery. -
Page 10: Technical Data
AS-i Safety Output Module with Diagnostic Slave Product Description Technical data Article no. VBA-4E2A1A-KE3-ZEL/E2L/SEL Inputs 3 standard, diagnostic + 1 EDM switching current static 4mA at 24V, dynamic 15mA at 24V (T = 100µs) Outputs 2 x output switching elements max. -
Page 11: Safety Relevant Data
AS-i Safety Output Module with Diagnostic Slave Product Description Safety relevant data Identification data Value Standard Safety category EN 13 849-1:2006/PLe Performance level (PL) Safety Integrity Level (SIL) IEC 61508 Usage time (TM) in years EN 13 849-1:2006/PLe Maximum operating time in months IEC 61508 IEC 61508 EN 62061 5,94... -
Page 12: Electrical Connection
AS-i Safety Output Module with Diagnostic Slave Product Description Electrical connection Clamps description I1, I2, I3 standard inputs I1, I2 and I3 1.14 semiconductor output 1 1.24 semiconductor output 2 I-, I+ supply voltage for inputs 1.Y1 EDM 1/ input for electronic device monitoring AS-i+, AS-i–... -
Page 13: Operating Interface
AS-i Safety Output Module with Diagnostic Slave Product Description Operating interface I – ext. out ext. out ext. out ext. out 1.Y1 Switches to select the operational mode: Normal operationing state I 3 1.Y1 addressing: safety slave (single address) FAULT addressing: 4I input slave (AB address) ADDR addressing: diagnostic slave (AB address) -
Page 14: Leds
AS-i Safety Output Module with Diagnostic Slave Product Description 5.5.1 LEDs LEDs Status Signal // Description green No supply power Supply power is on, safety-relevant address and/or AS-i AB address is “0” or no 24 V ext. in (auxiliary power) 1 Hz Supply power on FAULT... -
Page 15: Maintenance
AS-i Safety Output Module with Diagnostic Slave Maintenance Maintenance Controlling safe shutdowns The plant safety engineer is responsible for verifying that the AS-i Safety Output Module with Diagnostic Slave works correctly as part of the safety system. At least once a year it is necessary to verify the safe shutdown by initiating asso- ciated safety-related sensors or switchs: Attention! Press each safety-related AS-i slave and watch the reaction of the output circuits of the... -
Page 16: Address Assignment
Address Assignment The device offers three different types of AS-i addresses: Safety output VBA-4E2A1A-KE3-ZEL/E2L/SEL monitors communication on the safety address and switches based on the monitored data. This address can only be programmed if the switches are set to ON / PRG. -
Page 17: Programming The As-I Address Of The 4I Input Slave (Ab Address)
AS-i Safety Output Module with Diagnostic Slave Address Assignment Check slave’s ID2 code by using the hand-held addressing device or AS-i Master. The code should be the same as the ones-digit of the address. Check slave’s IO code by using the hand-held addressing device or AS-i Master. -
Page 18: Safety Requirements
