insys icom GSM small 2.0 Manual page 67

INSYS GSM small 2.0
Command
AT+IPR=<baud>
ATO
ATQ<n>
AT\Q<n>
ATS0?
Description
Configuring the baud rate of the serial interface
Note: It is not possible to change the baud rate for the i-modul UMTS 4.1
basic. The baud rate is fixed to 115200 bps here.
<baud> Specification of the baud rate in bps
AT+IPR=0
AT+IPR=300
AT+IPR=600
AT+IPR=1200
AT+IPR=2400
AT+IPR=4800
AT+IPR=9600
AT+IPR=14400
AT+IPR=19200
AT+IPR=38400
AT+IPR=57600
AT+IPR=115200
AT+IPR=230400
This setting is immediately stored (does not have to be stored with AT&W)
and is not reset with AT&F.
This command should not be in the same command line with other com-
mands.
Autobauding does not work with baud rates below 1200 bps.
We generally recommend not to work with autobauding, especially in con-
nection with automatic call acceptance (ATS0=<n>).
If autobauding is enabled, the TX input must not be firmly connected to
GND.
Returning to online data mode
Quiet control
This command enables or disables sending messages from the modem to
the PC
Sending messages to PC (default)
ATQ0
Sending no messages to PC
ATQ0
Data flow control of the serial interface
off (default)
AT\Q0
Software handshake (XON/XOFF)
AT\Q1
Hardware handshake (RTS/CTS)
AT\Q3
Querying automatic acceptance
AT Command Reference
Autobauding (default)
300 bps
600 bps
1200 bps
2400 bps
4800 bps
9600 bps
14400 bps
19200 bps
38400 bps
57600 bps
115200 bps
230400 bps
67
