INSYS GSM small 2.0
5. Push the SIM card holder with the inserted SIM card with the con-
tacts of the SIM card facing left into the INSYS GSM small 2.0.

The SIM card can now be used by the INSYS GSM small 2.0.

Please observe that the correct PIN is passed to the INSYS GSM small
2.0. A wrong PIN may cause that the SIM card will be locked after
switching on the INSYS GSM small 2.0.
Remove SIM card
How to remove the SIM card from the INSYS GSM small 2.0.

You will need a pointed object, e.g. a refill for a ballpoint pen.
1. Disable the power supply of the INSYS GSM small 2.0.
2. Press the eject button of the SIM card holder with the pointed object.

The SIM card holder will be ejected.
3. Remove the SIM card holder.
4. Remove the SIM card from the SIM card holder.
5. Push the SIM card holder back into the INSYS GSM small 2.0.
(similar representation)
