Technical Data
4 Technical Data
4.1 Physical Features
All specified data was measured with nominal input voltage, at full load, and an
ambient temperature of 25 °C. The limit value tolerances are subject to the usual
variations.
Physical Feature
Operating voltage
Power consumption standby
Power consumption connection
Power consumption power down
Power consumption sleep
Minimum SIM card operating voltage
Transmitted output:
EGSM 900: Class 4
GSM 1800: Class 1
EGSM 900: Class E2
GSM 1800: Class E2
Weight
Dimensions (Width x Depth x Height)
Temperature range
Maximum permissible humidity
Protection class
Table 1: Physical Features
16
Value
10 - 48 V DC ±5%
max. approx. 500 mW
max. approx. 2 W
max. approx. 200 mW
max. approx. 300 mW
1.8 or 3 V
2 W
1 W
0.5 W
0.5 W
125 g
23 x 120 x 75 mm
-20 °C – 55 °C
95% non-condensing
Housing IP40, Terminals IP20
