INSYS GSM small 2.0
11.12.1.2 Alarm Time
An alarm time can be defined for the internal real-time clock.
Configuration with HSComm
A configuration of this function using the HSComm software is not pos-
sible.
Configuration with AT commands
In order to configure the alarm time, use
the command
Replace <time> with the time in the format
<yy/mm/dd,hh:mm:ss> and <text> with the
text (max. 16 characters), which is to be
issued via the serial interface at alarm time.
If the INSYS GSM small 2.0 is in normal
mode at alarm time, it displays the mes-
sage
If the INSYS GSM small 2.0 is in Power-
Down mode at alarm time, the RTC alarm
mode will be entered and it displays the
message
After an alarm has occurred, the alarm time will be set to
"00/01/01,00:00:00", the parameter <text> is maintained.
AT+CALA=<time>[,0,0,<text>]
+CALA: <text>
^SYSSTART ALARM MODE
+CALA: <text>
