the XYZ axis mechanical coordinates. As shown in Figure 4-5, the plane center coordinates (X, Y,
Z) on the tool block are (30,30, -110).
Secondly, we enter the OTHER sub page under CONFIG. As shown in Figure 4-6, we find
fixed-point tool block location configuration item, and configure related parameters of cutter
block as shown in table 4-1.
No.
Mark
1
PROBE-PIN
2
PROBE-LEVEL 0
3
PROBE-MOD
4
PROBE-P-X
5
PROBE-P-Y
6
PROBE-P-Z
Table 4-1 Probe configuration item in fixed point probe mode
Probe configuration item screenshot see as figure 4-6.
Manual of NCH02
Value
Definition
2
Take IN2 Port as probe input port
The input port IN2 is low effective (effective when
the input short with GND)
0
Set to fixed-point probe mode
30
The X coordinate value of the position of the tool
sensor is 30
30
The Y coordinate value of the position of the tool
sensor is 30
-110
The Z coordinate value of the position of the tool
sensor is -110
- 41 -
