This card connect with MPG by this port. The port definition see as table 2-2
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
2.3.6 Spindle port
As Figure 2-2 showed,No.6 port is Spindle port. The interface definition is
VSO/GND/OT1/OT2 from left to right. Where VSO is the 0-10V analog output, OT1/OT2
digital drive signal output, spindle control output interface and spindle inverter connection
diagram figure 2-11. VSO/GND/OT1/OT2 are respectively connected with the inverter
AIN1/COM/X1/X2, where AIN1 is the input speed signal, COM converter X1 and X2 are the
Manual of NCH02
Mark
T1OUT
VMPG
WHA+
WHB+
XIN
ZIN
X100IN
EP
R1IN
GND
WHA-
WHB-
YIN
AIN
X10IN
Table 2-2. MPG port definition
- 14 -
Definition
TXD of Serial port
Power supply + for MPG(5V)
A phase positive of the encoder
B phase negative of the encoder
X axis select input
Z axis select input
100 rate select input
Estop port
RXD of Serial port
Ground and common end
A phase positive of the encoder
B phase negative of the encoder
Y axis select input
A axis select input
10 rate select input
