The file management page displays all the files in the U disk and can display the file name,
the size of the file, and the last modification date.
In the file management page, you can select the G code file you want to run by the knob.
When selected, press the knob confirmation key (PUSH) to load the G code file. After the load is
finished, the system automatically switches to the main page.

3.3 CONFIG Page

In the file management page, press
Press to switch the sub page of the configuration page. The parameter configuration
page contains 4 sub pages, respectively is the motor parameter configuration (MOTOR), input
configuration (INPUT), and the output spindle configuration (Spindle/OUT) and other(OTHER).
3.3.1 motor parameter configuration (MOTOR)
The motor parameter configuration page is shown in Figure 3-3. This page list specific
parameters by row, and list number axis by column. The parameters of the axis can be adjusted
by the knob.
Manual of NCH02
to enter the parameter configuration page.
